BAQ in Function

Max_Delgado · April 16, 2024, 8:35pm

Good afternoon and thank you in advance! I am fairly new to Epicor and I have built a function that checks a partNum to see if it has a revision, if it does not, it will create one, set the revision and give it a description. Now, it will work if I feed the function a single partNum. But I built a BAQ that shows me a full list of part numbers that do not have a revision. The client I am building this for, would like me to be able to run the function and all the part numbers in the list will be checked and dealt with accordingly.

What I really need help with is the C# code that handles bringing in my BAQ. I can provide my code if necessary, but considering the part that I have works, I didn’t feel it necessary.

I can modify my function to use the data returned from the BAQ if I could get some help getting said data into my function.

Thank you again!

klincecum · April 16, 2024, 8:56pm

Add Service Ice->BO->DynamicQuery to references for your library.

string baqName = "Woot";
string paramID = "Yo";

CallService<DynamicQuerySvcContract>(dq =>
{

  //if you need paramters
  //Ice.Tablesets.QueryExecutionTableset qets = dq.GetQueryExecutionParametersByID(baqName);
  //  var qParam = qets.ExecutionParameter.Where(p => p.ParameterID == paramID).FirstOrDefault();
  //  qParam.ParameterValue = "I am a smoking monkey in a yellow hat";

  //if you do not need paramters
  Ice.Tablesets.QueryExecutionTableset qets = new Ice.Tablesets.QueryExecutionTableset();

  DataSet ds = dq.ExecuteByID(baqName, qets);

});

Banderson · April 16, 2024, 9:01pm

My personal preference is usually to do the work actually right in the BAQ, and make it a UBAQ. You can call the BAQ with parameters, and then in the post processing get list (always happens) or a custom action (which you’ll have to fire yourself), I do the work. I do this because if I need the data anyways, it’s right there in the BAQ and available to you in the BPM engine attached to the BAQ. Then you don’t have to do the work in the function. You can still call the BAQ from the function to do things, but I find the data set easier to work with.

Both ways are valid, one just seems easier to me.

Hally · April 16, 2024, 11:44pm

As always there is no one correct answer

I built a function (with some help that will execute a given BAQ and will accept the BAQ name and a delimited string of the parameter pairs. This can be called from any function, and will accept any BAQ with any number of parameters and return the results… That’s the theory anyway.

You can call it from another function a bpm etc.

For the most part it works, but the using a colon as the pair separator is a bit of concern.


  //Request params
  //ParamList  System.String
  //BAQName  System.String

  //output params
  //dsRestult System.Data.Dataset
  //output System.String


  //Helper Function (Func<T>) to get THIS Function ID  https://www.epiusers.help/t/get-the-name-of-a-function/112406/4 Thanks Kev :)
    Func<string> GetFunctionID = () =>
  {
      string functionName = this.GetType().Name;
      string suffix = "Impl";

      return functionName.EndsWith(suffix) ? functionName.Remove(functionName.LastIndexOf(suffix)) : functionName;
  };

try
{
    this.CallService<Ice.Contracts.DynamicQuerySvcContract>(BAQSvc => {
        var ds = BAQSvc.GetByID(BAQName);
        var dqds = BAQSvc.GetQueryExecutionParametersByID(BAQName);


        //Split the parameter list into pairs and update the parameter values
        if (this.ParamList != null && dqds.ExecutionParameter.Count > 0)
        {
            var paramPairs = this.ParamList.Split('~');


            foreach (var pair in paramPairs)
            {
                var parts = pair.Split(':');
                if (parts.Length == 2)
                {
                    var paramName = parts[0];
                    var paramValue = parts[1];

                    var param = dqds.ExecutionParameter.Where(x => x.ParameterID == paramName).FirstOrDefault();

                    if (param != null)
                    {
                        param.ParameterValue = paramValue.ToString();
                        param.RowMod = "U";

                    }
                }
            }
        }
        else
        {
            //Yikes we have a problem Houston
            output = $"BAQ ID-{BAQName} : No parameters were passed to the BAQ Service or the BAQ Service does not have any parameters.";
            return;
        }

        //execute the BAQ
        this.dsResult = BAQSvc.ExecuteByID(BAQName, dqds);

    });
}
catch (Exception ex)
{
    // Handle the exception here
    string errMsg = $"{GetFunctionID()} ExecuteBAQ {BAQName}: An error occurred: {ex.Message}";
    Ice.Diagnostics.Log.WriteEntry(errMsg);
    throw new BLException(errMsg);

}

klincecum · April 17, 2024, 12:48am

Got an update for ya (of course that one works fine lol)

Hally · April 17, 2024, 12:51am

And of course I am looking at something else and I see that @kve already built something pretty similar and better…https://www.epiusers.help/t/helper-function-library-to-get-data-from-baqs-excel-files/110864

klincecum · April 17, 2024, 12:52am

We do that all the time here.
1334363166477_3983889

kve · April 17, 2024, 1:31am

while ( Wheel.Exists )
{
    thisLib.InventTheWheel();
}

klincecum · April 17, 2024, 1:35am

Mark?

Mark_Wonsil · April 17, 2024, 1:05pm

IMHO, I believe in building small tools that do one thing really well and combining them to do something useful. I would create a function that ONLY creates the location. Personally, I would turn to PowerShell, which is made to combine tools. The first would run that runs a BAQ into a Custom Object and I would pipe that into the call to the function that creates the locations. I would not try to do all of this in one function myself.

Max_Delgado · April 17, 2024, 1:55pm

I am unsure how to use what is in my ds object. When I type ds"." and press ctrl plus space, i am not seeing what I had anticipated which was the fields in my baq.

kve · April 17, 2024, 2:21pm

ds will be your BAQ results as type System.Data.DataSet.

You can loop through your BAQ rows with something like this:


foreach ( DataRow row in ds.Tables[0].Rows )
{
    string partNum = (string)row["Part_PartNum"]; // Use the Field Identifier from the Display Columns in your BAQ designer
}

Max_Delgado · April 17, 2024, 2:23pm

Nice! That was what I thought, but I was unsure of the syntax… Thank you so much! I am not ashamed to admit that I am still learning and this experience is helping me tremendously!

Max_Delgado · April 17, 2024, 5:35pm

Ok!! My function is working well! I am able to add a revision to a part, and add a short rev description. Customer just added that he would like the revision marked Approved. I found the method that runs after I competed a trace, however a box pops that states that a ‘Description of Change’ is needed. I cannot find in the trace though where this is added. A colleague of mine says that I cannot automate this in my function and that this box should be able to be turned off in the part menu. I am ok with either option. Does anyone have any insight into this?

Thanks you!

klincecum · April 17, 2024, 5:48pm

post the trace

Max_Delgado · April 17, 2024, 5:53pm

<tracePacket>
  <businessObject>Ice.Proxy.BO.UserTracingImpl</businessObject>
  <methodName>GetNewOrGetByID</methodName>
  <appServerUri>https://epicor2023.electri-cord.local/ERP11Test/</appServerUri>
  <returnType>Ice.BO.UserTracingDataSet</returnType>
  <localTime>4/17/2024 13:03:56:5814730 PM</localTime>
  <threadID>1</threadID>
  <correlationId>54711018-29c7-4561-a097-f54de6cd0ae0</correlationId>
  <executionTime total="6" roundTrip="4" channel="0" bpm="0" bpmDataForm="0" other="2" />
  <retries>0</retries>
  <parameters>
    <parameter name="UserID" type="System.String"><![CDATA[ComTec]]></parameter>
  </parameters>
</tracePacket>

<tracePacket>
  <businessObject>Ice.Proxy.BO.UserTracingImpl</businessObject>
  <methodName>Update</methodName>
  <appServerUri>https://epicor2023.electri-cord.local/ERP11Test/</appServerUri>
  <returnType>System.Void</returnType>
  <localTime>4/17/2024 13:03:56:5934207 PM</localTime>
  <threadID>1</threadID>
  <correlationId>162d7a2a-34eb-48df-b8e8-e7cf84005037</correlationId>
  <executionTime total="14" roundTrip="12" channel="0" bpm="0" bpmDataForm="0" other="2" />
  <retries>0</retries>
  <parameters>
    <parameter name="ds" type="Ice.BO.UserTracingDataSet">
      <UserTracingDataSet xmlns="http://www.epicor.com/Ice/300/BO/UserTracing/UserTracing">
        <UserTracing>
          <UserID>ComTec</UserID>
          <AssemblyReflector>Off</AssemblyReflector>
          <BitFlagViewWatcher>Off</BitFlagViewWatcher>
          <Catch>0</Catch>
          <CustomContext>Off</CustomContext>
          <DataTrace>false</DataTrace>
          <DataTraceCCDataSet>false</DataTraceCCDataSet>
          <DataTraceFullDataSets>false</DataTraceFullDataSets>
          <DataTraceIncludeServerTrace>false</DataTraceIncludeServerTrace>
          <DataTraceReturnData>false</DataTraceReturnData>
          <DataTraceDSChanges>false</DataTraceDSChanges>
          <DeploymentLogging>Off</DeploymentLogging>
          <DeregistrationException>Off</DeregistrationException>
          <DialogException>Off</DialogException>
          <FormLoad>Off</FormLoad>
          <LogException>Off</LogException>
          <NotifyAll>Off</NotifyAll>
          <TransactionLoad>Off</TransactionLoad>
          <DashboardException>Off</DashboardException>
          <TraceHelp>Off</TraceHelp>
          <UITraceLogDirectory>C:\Users\nable\AppData\Roaming\epicor\log</UITraceLogDirectory>
          <UITraceLocationScheme>Default from Epicor.exe.config file</UITraceLocationScheme>
          <SysRevID>3440575821</SysRevID>
          <SysRowID>fc8b8d9f-14ec-429f-a4d0-e451c8e7631b</SysRowID>
          <Kinetic>false</Kinetic>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </UserTracing>
      </UserTracingDataSet>
    </parameter>
    <parameter name="CallContext" type="Ice.Bpm.Context.ContextDataSet">
      <ContextDataSet xmlns="http://www.epicor.com/Ice/300/Bpm/Context">
        <BpmData>
          <SysRowID>fd1b562a-da40-4406-81dd-5459272815cd</SysRowID>
        </BpmData>
      </ContextDataSet>
    </parameter>
  </parameters>
</tracePacket>

<tracePacket>
  <businessObject>Ice.Proxy.BO.ReportMonitorImpl</businessObject>
  <methodName>GetRowsKeepIdleTimeWithBallonInfo</methodName>
  <appServerUri>https://epicor2023.electri-cord.local/ERP11Test/</appServerUri>
  <returnType>Ice.BO.ReportMonitorDataSet</returnType>
  <localTime>4/17/2024 13:03:58:6782253 PM</localTime>
  <threadID>24</threadID>
  <correlationId>a05900bd-4276-4cd6-91ef-a4444f9ff77c</correlationId>
  <executionTime total="5" roundTrip="4" channel="0" bpm="0" bpmDataForm="0" other="1" />
  <retries>0</retries>
  <parameters>
    <parameter name="whereClauseSysRptLst" type="System.String"><![CDATA[((PrintDriver='TEXT' AND (AutoAction='PRINT' OR AutoAction='PREVIEW')) OR (PrintDriver='CRYSTAL' AND (AutoAction='PRINT' OR AutoAction='AUTOPRT' OR AutoAction='PREVIEW' OR AutoAction='AUTOPRV' OR AutoAction='SSRSPREVIEW')) OR (PrintDriver='EPIFIN' AND (AutoAction='PRINT' OR AutoAction='PREVIEW')) OR (PrintDriver='BARTENDER' AND (AutoAction='AUTOPRT' OR AutoAction='AUTOPRV')) OR (PrintDriver='EDI' AND AutoAction<>'') OR (PrintDriver='SSRS' AND (AutoAction='PREVIEW' OR AutoAction='PRINT') AND LastAction='SSRSREADY')) AND (WorkStationID='EPICOR2023 6' OR WorkStationID='web_ComTec')]]></parameter>
    <parameter name="getBallonInfo" type="System.Boolean"><![CDATA[False]]></parameter>
    <parameter name="whereClauseSysTask" type="System.String"><![CDATA[history = true and startedon > 04/16/2024 and  SubmitUser = 'ComTec']]></parameter>
    <parameter name="whereClauseSysTaskLog" type="System.String"><![CDATA[]]></parameter>
    <parameter name="sysMonitorData" type="System.Data.DataSet">
      <NewDataSet />
    </parameter>
    <parameter name="CallContext" type="Ice.Bpm.Context.ContextDataSet">
      <ContextDataSet xmlns="http://www.epicor.com/Ice/300/Bpm/Context">
        <BpmData>
          <SysRowID>00000000-0000-0000-0000-000000000000</SysRowID>
        </BpmData>
      </ContextDataSet>
    </parameter>
  </parameters>
</tracePacket>

<tracePacket>
  <businessObject>Erp.Proxy.BO.PartImpl</businessObject>
  <methodName>PromptForPassword</methodName>
  <appServerUri>https://epicor2023.electri-cord.local/ERP11Test/</appServerUri>
  <returnType>System.Void</returnType>
  <localTime>4/17/2024 13:04:03:6463132 PM</localTime>
  <threadID>1</threadID>
  <correlationId>2b4a058f-a17c-4876-8934-26f8969022e4</correlationId>
  <executionTime total="9" roundTrip="7" channel="0" bpm="0" bpmDataForm="0" other="2" />
  <retries>0</retries>
  <parameters>
    <parameter name="CallContext" type="Ice.Bpm.Context.ContextDataSet">
      <ContextDataSet xmlns="http://www.epicor.com/Ice/300/Bpm/Context">
        <BpmData>
          <SysRowID>00000000-0000-0000-0000-000000000000</SysRowID>
        </BpmData>
      </ContextDataSet>
    </parameter>
  </parameters>
</tracePacket>

<tracePacket>
  <businessObject>Erp.Proxy.BO.PartImpl</businessObject>
  <methodName>ChangePartRevApproved</methodName>
  <appServerUri>https://epicor2023.electri-cord.local/ERP11Test/</appServerUri>
  <returnType>System.Void</returnType>
  <localTime>4/17/2024 13:04:03:6562696 PM</localTime>
  <threadID>1</threadID>
  <correlationId>d40a15b3-a407-4b02-905e-5ba6da1b59f8</correlationId>
  <executionTime total="21" roundTrip="18" channel="0" bpm="0" bpmDataForm="0" other="3" />
  <retries>0</retries>
  <parameters>
    <parameter name="ipApproved" type="System.Boolean"><![CDATA[True]]></parameter>
    <parameter name="ipValidPassword" type="System.Boolean"><![CDATA[True]]></parameter>
    <parameter name="ds" type="Erp.BO.PartDataSet">
      <PartDataSet xmlns="http://www.epicor.com/Ice/300/BO/Part/Part">
        <Part>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <SearchWord>1/0 AWG</SearchWord>
          <PartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartDescription>
          <ClassID>WIRE</ClassID>
          <IUM>FT</IUM>
          <PUM>FT</PUM>
          <TypeCode>P</TypeCode>
          <NonStock>false</NonStock>
          <PurchasingFactor>1.0000</PurchasingFactor>
          <UnitPrice>0.00000</UnitPrice>
          <PricePerCode>E</PricePerCode>
          <InternalUnitPrice>0.00000</InternalUnitPrice>
          <InternalPricePerCode>E</InternalPricePerCode>
          <ProdCode>OTHER</ProdCode>
          <MfgComment></MfgComment>
          <PurComment></PurComment>
          <CostMethod>S</CostMethod>
          <UserChar1></UserChar1>
          <UserChar2></UserChar2>
          <UserChar3></UserChar3>
          <UserChar4></UserChar4>
          <UserDecimal1>0.00</UserDecimal1>
          <UserDecimal2>0.00</UserDecimal2>
          <UserDecimal3>0.00000</UserDecimal3>
          <UserDecimal4>0.00000</UserDecimal4>
          <UserInteger1>0</UserInteger1>
          <UserInteger2>0</UserInteger2>
          <TaxCatID></TaxCatID>
          <InActive>false</InActive>
          <LowLevelCode>0</LowLevelCode>
          <Method>false</Method>
          <TrackLots>false</TrackLots>
          <TrackDimension>false</TrackDimension>
          <DefaultDim></DefaultDim>
          <TrackSerialNum>false</TrackSerialNum>
          <CommodityCode></CommodityCode>
          <WarrantyCode></WarrantyCode>
          <PhantomBOM>false</PhantomBOM>
          <SalesUM>FT</SalesUM>
          <SellingFactor>1.00000000</SellingFactor>
          <MtlBurRate>0.00000</MtlBurRate>
          <NetWeight>0.00000</NetWeight>
          <UsePartRev>true</UsePartRev>
          <PartsPerContainer>0</PartsPerContainer>
          <PartLength>0.00000</PartLength>
          <PartWidth>0.00000</PartWidth>
          <PartHeight>0.00000</PartHeight>
          <LotShelfLife>0</LotShelfLife>
          <WebPart>false</WebPart>
          <RunOut>false</RunOut>
          <SubPart></SubPart>
          <Diameter>0.00000</Diameter>
          <Gravity>0.00000</Gravity>
          <OnHold>false</OnHold>
          <OnHoldReasonCode></OnHoldReasonCode>
          <AnalysisCode></AnalysisCode>
          <GlobalPart>true</GlobalPart>
          <MtlAnalysisCode></MtlAnalysisCode>
          <GlobalLock>false</GlobalLock>
          <ISSuppUnitsFactor>1.00000000</ISSuppUnitsFactor>
          <PDMObjID></PDMObjID>
          <ImageFileName></ImageFileName>
          <ISOrigCountry>0</ISOrigCountry>
          <SNPrefix></SNPrefix>
          <SNFormat></SNFormat>
          <SNBaseDataType></SNBaseDataType>
          <Constrained>true</Constrained>
          <UPCCode1></UPCCode1>
          <UPCCode2></UPCCode2>
          <UPCCode3></UPCCode3>
          <EDICode></EDICode>
          <WebInStock>false</WebInStock>
          <ConsolidatedPurchasing>false</ConsolidatedPurchasing>
          <PurchasingFactorDirection>D</PurchasingFactorDirection>
          <SellingFactorDirection>D</SellingFactorDirection>
          <RecDocReq>false</RecDocReq>
          <MDPV>0</MDPV>
          <ShipDocReq>false</ShipDocReq>
          <ReturnableContainer></ReturnableContainer>
          <NetVolume>0.00000</NetVolume>
          <QtyBearing>true</QtyBearing>
          <NAFTAOrigCountry></NAFTAOrigCountry>
          <NAFTAProd></NAFTAProd>
          <NAFTAPref></NAFTAPref>
          <ExpLicType></ExpLicType>
          <ExpLicNumber></ExpLicNumber>
          <ECCNNumber></ECCNNumber>
          <AESExp></AESExp>
          <HTS></HTS>
          <UseHTSDesc>false</UseHTSDesc>
          <SchedBcode></SchedBcode>
          <HazItem>false</HazItem>
          <HazTechName></HazTechName>
          <HazClass></HazClass>
          <HazSub></HazSub>
          <HazGvrnmtID></HazGvrnmtID>
          <HazPackInstr></HazPackInstr>
          <RevChargeMethod></RevChargeMethod>
          <RCUnderThreshold>0.000</RCUnderThreshold>
          <RCOverThreshold>0.000</RCOverThreshold>
          <OwnershipStatus></OwnershipStatus>
          <UOMClassID>LENGTH</UOMClassID>
          <SNMask></SNMask>
          <SNMaskExample></SNMaskExample>
          <SNMaskSuffix></SNMaskSuffix>
          <SNMaskPrefix></SNMaskPrefix>
          <SNLastUsedSeq></SNLastUsedSeq>
          <UseMaskSeq>false</UseMaskSeq>
          <NetWeightUOM>OZ</NetWeightUOM>
          <NetVolumeUOM>FZ</NetVolumeUOM>
          <LotBatch>false</LotBatch>
          <LotMfgBatch>false</LotMfgBatch>
          <LotMfgLot>false</LotMfgLot>
          <LotHeat>false</LotHeat>
          <LotFirmware>false</LotFirmware>
          <LotBeforeDt>false</LotBeforeDt>
          <LotMfgDt>false</LotMfgDt>
          <LotCureDt>false</LotCureDt>
          <LotExpDt>false</LotExpDt>
          <LotPrefix></LotPrefix>
          <LotUseGlobalSeq>false</LotUseGlobalSeq>
          <LotSeqID></LotSeqID>
          <LotNxtNum>1</LotNxtNum>
          <LotDigits>0</LotDigits>
          <LotLeadingZeros>false</LotLeadingZeros>
          <LotAppendDate></LotAppendDate>
          <BuyToOrder>false</BuyToOrder>
          <DropShip>false</DropShip>
          <IsConfigured>false</IsConfigured>
          <ExtConfig>false</ExtConfig>
          <RefCategory></RefCategory>
          <CSFCJ5>false</CSFCJ5>
          <CSFLMW>false</CSFLMW>
          <GrossWeight>0.00000</GrossWeight>
          <GrossWeightUOM>OZ</GrossWeightUOM>
          <BasePartNum></BasePartNum>
          <FSAssetClassCode></FSAssetClassCode>
          <FSSalesUnitPrice>0.00000</FSSalesUnitPrice>
          <FSPricePerCode>E</FSPricePerCode>
          <RcvInspectionReq>false</RcvInspectionReq>
          <EstimateID></EstimateID>
          <EstimateOrPlan></EstimateOrPlan>
          <DiffPrc2PrchUOM>false</DiffPrc2PrchUOM>
          <DupOnJobCrt>false</DupOnJobCrt>
          <PricingFactor>0.00000</PricingFactor>
          <PricingUOM></PricingUOM>
          <MobilePart>true</MobilePart>
          <SysRevID>595291056</SysRevID>
          <SysRowID>f300f95b-4bca-1d81-e211-07ef40ef2798</SysRowID>
          <AGUseGoodMark>false</AGUseGoodMark>
          <AGProductMark>false</AGProductMark>
          <ISRegion></ISRegion>
          <INChapterID></INChapterID>
          <PESUNATType></PESUNATType>
          <PESUNATUOM></PESUNATUOM>
          <DEIsServices>false</DEIsServices>
          <DEIsSecurityFinancialDerivative>false</DEIsSecurityFinancialDerivative>
          <DEInternationalSecuritiesID></DEInternationalSecuritiesID>
          <LinkToContract>false</LinkToContract>
          <DEIsInvestment>false</DEIsInvestment>
          <DEPayStatCode>0</DEPayStatCode>
          <DEDenomination></DEDenomination>
          <PartLengthWidthHeightUM></PartLengthWidthHeightUM>
          <DiameterUM></DiameterUM>
          <DiameterInside>0.00000</DiameterInside>
          <DiameterOutside>0.00000</DiameterOutside>
          <ThicknessUM></ThicknessUM>
          <Thickness>0.00000</Thickness>
          <ThicknessMax>0.00000</ThicknessMax>
          <Durometer></Durometer>
          <Specification></Specification>
          <EngineeringAlert></EngineeringAlert>
          <Condition></Condition>
          <IsCompliant>false</IsCompliant>
          <IsRestricted>false</IsRestricted>
          <IsSafetyItem>false</IsSafetyItem>
          <CommercialBrand></CommercialBrand>
          <CommercialSubBrand></CommercialSubBrand>
          <CommercialCategory></CommercialCategory>
          <CommercialSubCategory></CommercialSubCategory>
          <CommercialStyle></CommercialStyle>
          <CommercialSize1></CommercialSize1>
          <CommercialSize2></CommercialSize2>
          <CommercialColor></CommercialColor>
          <IsGiftCard>false</IsGiftCard>
          <PhotoFile></PhotoFile>
          <PartPhotoExists>false</PartPhotoExists>
          <CommentText></CommentText>
          <PartSpecificPackingUOM>false</PartSpecificPackingUOM>
          <ImageID></ImageID>
          <CNSpecification></CNSpecification>
          <SyncToExternalCRM>false</SyncToExternalCRM>
          <ExternalCRMPartID></ExternalCRMPartID>
          <ExternalCRMSyncRequired>false</ExternalCRMSyncRequired>
          <PESUNATTypeCode></PESUNATTypeCode>
          <PESUNATUOMCode></PESUNATUOMCode>
          <CNCodeVersion></CNCodeVersion>
          <CNTaxCategoryCode></CNTaxCategoryCode>
          <CNHasPreferentialTreatment>false</CNHasPreferentialTreatment>
          <CNPreferentialTreatmentContent></CNPreferentialTreatmentContent>
          <CNZeroTaxRateMark></CNZeroTaxRateMark>
          <SubLevelCode>0</SubLevelCode>
          <CreatedBy></CreatedBy>
          <AttBatch>N</AttBatch>
          <AttMfgBatch>N</AttMfgBatch>
          <AttMfgLot>N</AttMfgLot>
          <AttHeat>N</AttHeat>
          <AttFirmware>N</AttFirmware>
          <AttBeforeDt>N</AttBeforeDt>
          <AttMfgDt>N</AttMfgDt>
          <AttCureDt>N</AttCureDt>
          <AttExpDt>N</AttExpDt>
          <DeferManualEntry>false</DeferManualEntry>
          <DeferPurchaseReceipt>false</DeferPurchaseReceipt>
          <DeferJobReceipt>false</DeferJobReceipt>
          <DeferInspection>false</DeferInspection>
          <DeferQtyAdjustment>false</DeferQtyAdjustment>
          <DeferInventoryMove>false</DeferInventoryMove>
          <DeferShipments>false</DeferShipments>
          <DeferInventoryCounts>false</DeferInventoryCounts>
          <DeferAssetDisposal>false</DeferAssetDisposal>
          <DeferReturnMaterials>false</DeferReturnMaterials>
          <MXProdServCode></MXProdServCode>
          <MXCustomsDuty></MXCustomsDuty>
          <SendToFSA>false</SendToFSA>
          <ExternalMESSyncRequired>false</ExternalMESSyncRequired>
          <FSAItem>false</FSAItem>
          <FSAEquipment>false</FSAEquipment>
          <BOLClass></BOLClass>
          <FairMarketValue>0.00000</FairMarketValue>
          <SAFTProdCategory></SAFTProdCategory>
          <AttrClassID></AttrClassID>
          <LocationIDNumReq>false</LocationIDNumReq>
          <LocationTrackInv>false</LocationTrackInv>
          <LocationMtlView>false</LocationMtlView>
          <LCNRVReporting>false</LCNRVReporting>
          <LCNRVEstimatedUnitPrice>0.000</LCNRVEstimatedUnitPrice>
          <MXCustomsUMFrom></MXCustomsUMFrom>
          <LocationFormatID></LocationFormatID>
          <IsServices>false</IsServices>
          <PEDetrGoodServiceCode></PEDetrGoodServiceCode>
          <PEProductServiceCode></PEProductServiceCode>
          <DualUOMClassID></DualUOMClassID>
          <CNProductName></CNProductName>
          <CNWeight>0.00000</CNWeight>
          <CNWeightUOM></CNWeightUOM>
          <CNBonded>false</CNBonded>
          <TrackInventoryAttributes>false</TrackInventoryAttributes>
          <DefaultAttributeSetID>0</DefaultAttributeSetID>
          <AttISOrigCountry>N</AttISOrigCountry>
          <ExternalSchemeID></ExternalSchemeID>
          <ExternalID></ExternalID>
          <CommoditySchemeID></CommoditySchemeID>
          <CommoditySchemeVersion></CommoditySchemeVersion>
          <TrackInventoryByRevision>false</TrackInventoryByRevision>
          <PlanningByRevision>false</PlanningByRevision>
          <CountryNumDescription></CountryNumDescription>
          <EnableExpressCheckOut>false</EnableExpressCheckOut>
          <EnableGlobalLock>false</EnableGlobalLock>
          <EnableGlobalPart>true</EnableGlobalPart>
          <EnableInActive>true</EnableInActive>
          <EnableIUM>false</EnableIUM>
          <EnableRevCharge>false</EnableRevCharge>
          <EnableSerialNum>false</EnableSerialNum>
          <EnableTrackSerialNum>true</EnableTrackSerialNum>
          <EnableUOMClass>false</EnableUOMClass>
          <ExtCoExist>true</ExtCoExist>
          <FSAInstallationCost>0.00000</FSAInstallationCost>
          <FSAInstallationRequired>false</FSAInstallationRequired>
          <FSAInstallationType></FSAInstallationType>
          <FSAInstTypeDesc></FSAInstTypeDesc>
          <GlbFlag>true</GlbFlag>
          <GlbLink></GlbLink>
          <GlbTableAllowUpdTrackDim>false</GlbTableAllowUpdTrackDim>
          <GlbTableAllowUpdTrackLots>false</GlbTableAllowUpdTrackLots>
          <GlbTableAllowUpdTrackSerial>false</GlbTableAllowUpdTrackSerial>
          <HasOnHandQty>false</HasOnHandQty>
          <IsComponent>false</IsComponent>
          <IsCoPart>false</IsCoPart>
          <ISOrigCountryNum>0</ISOrigCountryNum>
          <NextGeneratedLotNum></NextGeneratedLotNum>
          <PEDetrGoodServiceCodeDesc></PEDetrGoodServiceCodeDesc>
          <PEProductServiceCodeDesc></PEProductServiceCodeDesc>
          <PLM>false</PLM>
          <PLMEnabled>false</PLMEnabled>
          <Revision>false</Revision>
          <SalesUMDisp>FT</SalesUMDisp>
          <SNLeadingZeros>false</SNLeadingZeros>
          <SNMaskPrefixLength>0</SNMaskPrefixLength>
          <SNMaskSuffixLength>0</SNMaskSuffixLength>
          <SNNumODigits>0</SNNumODigits>
          <UpdatePartPlant>false</UpdatePartPlant>
          <UpdateSNPartPlant>false</UpdateSNPartPlant>
          <COASegReferences></COASegReferences>
          <HasMRPPlanningAttribute>false</HasMRPPlanningAttribute>
          <UpdatePartPlantOverride>false</UpdatePartPlantOverride>
          <DEPayStatCodeDescr></DEPayStatCodeDescr>
          <DEDenominationDescr></DEDenominationDescr>
          <BitFlag>8</BitFlag>
          <AnalysisCdDescription></AnalysisCdDescription>
          <ClassDescription>WIRE</ClassDescription>
          <CommodityCodeSuppUnitsUOM></CommodityCodeSuppUnitsUOM>
          <CommodityCodeDescription></CommodityCodeDescription>
          <CompanySendToFSA>false</CompanySendToFSA>
          <DualUOMClassIDDescription></DualUOMClassIDDescription>
          <DynAttrValueSetShortDescription></DynAttrValueSetShortDescription>
          <DynAttrValueSetDescription></DynAttrValueSetDescription>
          <FSAssetClassCodeFSAssetClassDesc></FSAssetClassCodeFSAssetClassDesc>
          <Mtl_AnalysisCdDescription></Mtl_AnalysisCdDescription>
          <MXProdServCodeDesc></MXProdServCodeDesc>
          <OnHoldReasonCodeDescription></OnHoldReasonCodeDescription>
          <ProdCodeDescription>OTHER</ProdCodeDescription>
          <RefCategoryDescription></RefCategoryDescription>
          <SerialMaskMaskType>0</SerialMaskMaskType>
          <SerialMaskDescription></SerialMaskDescription>
          <TaxCatIDDescription></TaxCatIDDescription>
          <UOMClassIDDescription>LENGTH</UOMClassIDDescription>
          <WarrantyCodeWarrDescription></WarrantyCodeWarrDescription>
          <XbSystELIEinvoice>true</XbSystELIEinvoice>
          <RowMod></RowMod>
          <Character01></Character01>
          <Character02></Character02>
          <Character03></Character03>
          <Character05></Character05>
          <Number01>0.000000000</Number01>
          <Number05>0.000000000</Number05>
          <Number06>0.000000000</Number06>
          <CheckBox01>true</CheckBox01>
          <CheckBox02>false</CheckBox02>
          <CheckBox03>false</CheckBox03>
          <CheckBox05>false</CheckBox05>
          <CheckBox06>false</CheckBox06>
          <CheckBox07>false</CheckBox07>
          <CheckBox08>false</CheckBox08>
          <ShortChar01></ShortChar01>
          <ShortChar02>Inspect</ShortChar02>
          <ShortChar03></ShortChar03>
          <ShortChar04></ShortChar04>
          <ShortChar05></ShortChar05>
          <ShortChar06></ShortChar06>
          <ShortChar07></ShortChar07>
          <ShortChar08></ShortChar08>
          <ShortChar09></ShortChar09>
          <ShortChar10></ShortChar10>
          <CheckBox04>false</CheckBox04>
          <MinSellQty_c>0.00</MinSellQty_c>
          <Forecasted_c>false</Forecasted_c>
          <ISO13485_c>false</ISO13485_c>
          <TS_16949_c>false</TS_16949_c>
          <CCN_c></CCN_c>
          <ULListed_c>false</ULListed_c>
          <ApprovedMargin_c>0.00</ApprovedMargin_c>
          <TariffCustomer_c>0.00</TariffCustomer_c>
          <TariffSupplier_c>0.00</TariffSupplier_c>
          <Prop65_c>false</Prop65_c>
          <Amortized_c>false</Amortized_c>
          <Commission1_c>0.00000</Commission1_c>
          <Commission2_c>0.00000</Commission2_c>
          <DiscountPct_c>0.00000</DiscountPct_c>
          <CopyExact_c>false</CopyExact_c>
          <CSRMX_c></CSRMX_c>
          <CSRUS_c></CSRUS_c>
          <ASM3CELL_c>false</ASM3CELL_c>
          <Engineer_c></Engineer_c>
          <CopperWeight_c>0.00000</CopperWeight_c>
          <UD_SysRevID>AAAAAAQS4V0=</UD_SysRevID>
        </Part>
        <PartPlant>
          <Company>ECM</Company>
          <Plant>MfgSys</Plant>
          <PartNum>10.1761</PartNum>
          <PrimWhse>RAW</PrimWhse>
          <MinimumQty>0.00000000</MinimumQty>
          <MaximumQty>0.00000000</MaximumQty>
          <SafetyQty>0.00000000</SafetyQty>
          <MinOrderQty>1000.00000000</MinOrderQty>
          <LeadTime>10</LeadTime>
          <VendorNum>20</VendorNum>
          <PurPoint>1</PurPoint>
          <BackFlush>false</BackFlush>
          <MfgLotSize>0.00</MfgLotSize>
          <MinMfgLotSize>0.00</MinMfgLotSize>
          <MaxMfgLotSize>0.00</MaxMfgLotSize>
          <MfgLotMultiple>0.00</MfgLotMultiple>
          <DaysOfSupply>30</DaysOfSupply>
          <ReOrderLevel>false</ReOrderLevel>
          <MRPRecalcNeeded>false</MRPRecalcNeeded>
          <ProcessMRP>true</ProcessMRP>
          <GenerateSugg>true</GenerateSugg>
          <GetFromLocalWhse>false</GetFromLocalWhse>
          <ForecastTime>0</ForecastTime>
          <TransferPlant></TransferPlant>
          <SourceType>P</SourceType>
          <TransferLeadTime>0</TransferLeadTime>
          <PrepTime>0</PrepTime>
          <ReceiveTime>0</ReceiveTime>
          <PlanTimeFence>0</PlanTimeFence>
          <ReschedOutDelta>0</ReschedOutDelta>
          <ReschedInDelta>0</ReschedInDelta>
          <NonStock>false</NonStock>
          <PhantomBOM>false</PhantomBOM>
          <BuyerID></BuyerID>
          <PersonID></PersonID>
          <CostMethod>S</CostMethod>
          <AltMethod></AltMethod>
          <KitTime>0</KitTime>
          <KitAllowUpdate>false</KitAllowUpdate>
          <KitShipComplete>true</KitShipComplete>
          <KitAllowChangeParms>false</KitAllowChangeParms>
          <KitBackFlush>false</KitBackFlush>
          <KitPricing>P</KitPricing>
          <KitPrintCompsPS>true</KitPrintCompsPS>
          <KitPrintCompsInv>true</KitPrintCompsInv>
          <ShortHorizonDays>0</ShortHorizonDays>
          <ShortHorizonMinMfgLotSize>0.00</ShortHorizonMinMfgLotSize>
          <ShortHorizonMaxMfgLotSize>0.00</ShortHorizonMaxMfgLotSize>
          <LimitProdYldRecalc>false</LimitProdYldRecalc>
          <QtyBearing>true</QtyBearing>
          <MRPLastRunDate>2024-03-06T00:00:00-05:00</MRPLastRunDate>
          <MRPLastRunTime>36930</MRPLastRunTime>
          <MRPLastScheduledDate>2024-01-02T00:00:00-05:00</MRPLastScheduledDate>
          <ShortHorizonDaysSupp>0</ShortHorizonDaysSupp>
          <SNMask></SNMask>
          <SNMaskExample></SNMaskExample>
          <SNBaseDataType></SNBaseDataType>
          <SNFormat></SNFormat>
          <SNPrefix></SNPrefix>
          <SNMaskSuffix></SNMaskSuffix>
          <SNMaskPrefix></SNMaskPrefix>
          <SNLastUsedSeq></SNLastUsedSeq>
          <UseMaskSeq>false</UseMaskSeq>
          <BuyToOrder>false</BuyToOrder>
          <DropShip>false</DropShip>
          <PcntTolerance>0.00</PcntTolerance>
          <CalcPcnt>false</CalcPcnt>
          <CalcQty>false</CalcQty>
          <CalcValue>false</CalcValue>
          <QtyAdjTolerance>0.00000000</QtyAdjTolerance>
          <QtyTolerance>0</QtyTolerance>
          <ValueTolerance>0</ValueTolerance>
          <DemandQty>0.00000000</DemandQty>
          <ReservedQty>0.00000000</ReservedQty>
          <AllocatedQty>0.00000000</AllocatedQty>
          <XRefPartNum></XRefPartNum>
          <XRefPartType></XRefPartType>
          <NeverReuseMRPJob>false</NeverReuseMRPJob>
          <DeleteMRPJobs>false</DeleteMRPJobs>
          <TotMfgLeadTimeSys>0</TotMfgLeadTimeSys>
          <TotMfgLeadTimeMnl>0</TotMfgLeadTimeMnl>
          <LvlMfgLeadTimeSys>0</LvlMfgLeadTimeSys>
          <LvlMfgLeadTimeMnl>0</LvlMfgLeadTimeMnl>
          <AutoConsumeStock>false</AutoConsumeStock>
          <StartMinLotQty>false</StartMinLotQty>
          <MinLotLeadTime>0</MinLotLeadTime>
          <MfgLeadTimeMnl>false</MfgLeadTimeMnl>
          <MfgLeadTimeEnteredBy></MfgLeadTimeEnteredBy>
          <MinStartQty>0.00000000</MinStartQty>
          <RawMaterial>false</RawMaterial>
          <MultiLevelCTP>false</MultiLevelCTP>
          <RcvInspectionReq>false</RcvInspectionReq>
          <ConsumeSafety>false</ConsumeSafety>
          <SLTVendorNum>0</SLTVendorNum>
          <SLTPurPoint></SLTPurPoint>
          <ShortLeadTime>0</ShortLeadTime>
          <ExternalMES>false</ExternalMES>
          <SysRevID>3440777672</SysRevID>
          <SysRowID>f300f95b-4bca-1d81-e211-07ef50602a98</SysRowID>
          <UrgentLeadTime>0</UrgentLeadTime>
          <UrgentMinOrdQty>0.00000000</UrgentMinOrdQty>
          <UrgentMultQty>0.00</UrgentMultQty>
          <UrgentPurPoint></UrgentPurPoint>
          <UrgentVendorNum>0</UrgentVendorNum>
          <PartRunMRP>false</PartRunMRP>
          <LinkToContract>false</LinkToContract>
          <MMSExclude>false</MMSExclude>
          <MMSSales>false</MMSSales>
          <MMSIssue>false</MMSIssue>
          <MMSHistory>0</MMSHistory>
          <MMSSafetyFactor>0</MMSSafetyFactor>
          <MMSMaxFactor>0.00</MMSMaxFactor>
          <SavedMinimumQty>0.00000000</SavedMinimumQty>
          <SavedMaximumQty>0.00000000</SavedMaximumQty>
          <SavedSafetyQty>0.00000000</SavedSafetyQty>
          <SavedCalculatedUsageQty>0.00000000</SavedCalculatedUsageQty>
          <ACWPercentage>0</ACWPercentage>
          <ACWDays>0</ACWDays>
          <GenNewPCIDDelaySeconds>0</GenNewPCIDDelaySeconds>
          <GenNewPCIDLimitDays>0</GenNewPCIDLimitDays>
          <TopLvlMfgLeadTimeSys>0</TopLvlMfgLeadTimeSys>
          <TopLvlMfgLeadTimeMnl>0</TopLvlMfgLeadTimeMnl>
          <ActualCostingCategoryID></ActualCostingCategoryID>
          <IncludedIntoAllocationBase>false</IncludedIntoAllocationBase>
          <ForecastDaysBefore>0</ForecastDaysBefore>
          <ForecastDaysAfter>0</ForecastDaysAfter>
          <BaseUOMCode>FT</BaseUOMCode>
          <CalculatedLeadTime>10</CalculatedLeadTime>
          <ExtLeadTime>0</ExtLeadTime>
          <SNNumODigits>0</SNNumODigits>
          <UrgentVendorName></UrgentVendorName>
          <UrgentVendorVendorID></UrgentVendorVendorID>
          <DisableQtyBrng>false</DisableQtyBrng>
          <EnableSerialNum>false</EnableSerialNum>
          <ICTrader>false</ICTrader>
          <InActive>false</InActive>
          <OnHandQty>0</OnHandQty>
          <PlantConfCtrlSerialTracking>1</PlantConfCtrlSerialTracking>
          <SNLeadingZeros>false</SNLeadingZeros>
          <HasOnHandQty>false</HasOnHandQty>
          <IsActCostingAllocEnabled>false</IsActCostingAllocEnabled>
          <MaximumQtyNofP>0.00000000</MaximumQtyNofP>
          <MaxMfgLotSizeNofP>0.00000000</MaxMfgLotSizeNofP>
          <MfgLotMultipleNofP>0.00000000</MfgLotMultipleNofP>
          <MinimumQtyNofP>0.00000000</MinimumQtyNofP>
          <MinMfgLotSizeNofP>0.00000000</MinMfgLotSizeNofP>
          <MinOrderQtyNofP>0.00000000</MinOrderQtyNofP>
          <MinStartQtyNofP>0.00000000</MinStartQtyNofP>
          <QtyDisplayOption></QtyDisplayOption>
          <SafetyQtyNofP>0.00000000</SafetyQtyNofP>
          <ShortHorizonMaxMfgLotSizeNofP>0.00000000</ShortHorizonMaxMfgLotSizeNofP>
          <ShortHorizonMinMfgLotSizeNofP>0.00000000</ShortHorizonMinMfgLotSizeNofP>
          <UrgentMinOrdQtyNofP>0.00000000</UrgentMinOrdQtyNofP>
          <UrgentMultQtyNofP>0.00000000</UrgentMultQtyNofP>
          <BitFlag>8</BitFlag>
          <BuyerIDName></BuyerIDName>
          <PartTrackInventoryAttributes>false</PartTrackInventoryAttributes>
          <PartAttrClassID></PartAttrClassID>
          <PartSellingFactor>1.00000000</PartSellingFactor>
          <PartTrackLots>false</PartTrackLots>
          <PartTrackSerialNum>false</PartTrackSerialNum>
          <PartTrackDimension>false</PartTrackDimension>
          <PartIUM>FT</PartIUM>
          <PartPricePerCode>E</PartPricePerCode>
          <PartPartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartPartDescription>
          <PartSalesUM>FT</PartSalesUM>
          <PersonName></PersonName>
          <PlantName>ELECTRI-CORD MFG - PA PLANT</PlantName>
          <PrimWhseDescription>RAW MATERIAL</PrimWhseDescription>
          <SerialMaskMaskType>0</SerialMaskMaskType>
          <SerialMaskDescription></SerialMaskDescription>
          <TransferPlantName></TransferPlantName>
          <VendorNumAddress1>PO BOX 26157</VendorNumAddress1>
          <VendorNumState>PA</VendorNumState>
          <VendorNumCountry>UNITED STATES</VendorNumCountry>
          <VendorNumCity>COLLEGEVILLE</VendorNumCity>
          <VendorNumCurrencyCode>BASE</VendorNumCurrencyCode>
          <VendorNumDefaultFOB>FOBSHIP</VendorNumDefaultFOB>
          <VendorNumAddress2></VendorNumAddress2>
          <VendorNumZIP>26157</VendorNumZIP>
          <VendorNumTermsCode>N60</VendorNumTermsCode>
          <VendorNumAddress3></VendorNumAddress3>
          <VendorNumName>ALLIED WIRE &amp; CABLE</VendorNumName>
          <VendorNumVendorID>1018</VendorNumVendorID>
          <RowMod></RowMod>
          <Character01></Character01>
          <Character02></Character02>
          <Character03></Character03>
          <Character04></Character04>
          <Character05></Character05>
          <Character06></Character06>
          <Number01>0.000000000</Number01>
          <CheckBox01>false</CheckBox01>
          <ToolingCap_c>0.00</ToolingCap_c>
          <UD_SysRevID>AAAAAAQMCfI=</UD_SysRevID>
        </PartPlant>
        <PartRev>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <RevisionNum>-</RevisionNum>
          <RevShortDesc>Default</RevShortDesc>
          <RevDescription></RevDescription>
          <Approved>true</Approved>
          <ApprovedBy></ApprovedBy>
          <EffectiveDate>2024-04-17T00:00:00-04:00</EffectiveDate>
          <TLRLaborCost>0.00000</TLRLaborCost>
          <TLRBurdenCost>0.00000</TLRBurdenCost>
          <TLRMaterialCost>0.00000</TLRMaterialCost>
          <TLRSubcontractCost>0.00000</TLRSubcontractCost>
          <TLRMtlBurCost>0.00000</TLRMtlBurCost>
          <TLRSetupLaborCost>0.00000</TLRSetupLaborCost>
          <TLRSetupBurdenCost>0.00000</TLRSetupBurdenCost>
          <LLRLaborCost>0.00000</LLRLaborCost>
          <LLRBurdenCost>0.00000</LLRBurdenCost>
          <LLRMaterialCost>0.00000</LLRMaterialCost>
          <LLRSubcontractCost>0.00000</LLRSubcontractCost>
          <LLRMtlBurCost>0.00000</LLRMtlBurCost>
          <LLRSetupLaborCost>0.00000</LLRSetupLaborCost>
          <LLRSetupBurdenCost>0.00000</LLRSetupBurdenCost>
          <DrawNum></DrawNum>
          <ECO></ECO>
          <Method>false</Method>
          <AutoRecOpr>0</AutoRecOpr>
          <FinalOpr>0</FinalOpr>
          <PDMObjID></PDMObjID>
          <Configured>false</Configured>
          <WebConfigured>false</WebConfigured>
          <ShowInputPrice>false</ShowInputPrice>
          <AltMethod></AltMethod>
          <AltMethodDesc></AltMethodDesc>
          <Plant>MN</Plant>
          <ParentAltMethod></ParentAltMethod>
          <UseStaging>false</UseStaging>
          <UseAltRevForParts>false</UseAltRevForParts>
          <OwnershipStatus></OwnershipStatus>
          <ExtConfig>false</ExtConfig>
          <ValRefDes>false</ValRefDes>
          <PcGlobalPart>false</PcGlobalPart>
          <PcEntprsConf>false</PcEntprsConf>
          <GlobalRev>false</GlobalRev>
          <RoughCutCode></RoughCutCode>
          <RMAInspPlan></RMAInspPlan>
          <RMASpecID></RMASpecID>
          <RMASampleSize>0.00000000</RMASampleSize>
          <RMASampleSizePct>0.00</RMASampleSizePct>
          <BasePartNum></BasePartNum>
          <BaseRevisionNum></BaseRevisionNum>
          <ConfigID></ConfigID>
          <RegenConfig>false</RegenConfig>
          <SIValuesGroupSeq>0</SIValuesGroupSeq>
          <SIValuesHeadNum>0</SIValuesHeadNum>
          <ExternalMES>false</ExternalMES>
          <SysRevID>3441156476</SysRevID>
          <SysRowID>cf469999-a5fa-4667-a855-083e04d9fbc3</SysRowID>
          <ProcessMode>S</ProcessMode>
          <DefaultConfigPart>false</DefaultConfigPart>
          <CoPartsReqQty>0.00000000</CoPartsReqQty>
          <MtlCostPct>0.00000</MtlCostPct>
          <LaborCostPct>0.00000</LaborCostPct>
          <CoPartsPerOp>0</CoPartsPerOp>
          <CreatedBy>ComTec</CreatedBy>
          <CreatedOn>2024-04-17T16:55:30.773-04:00</CreatedOn>
          <ChangedBy>ComTec</ChangedBy>
          <ChangedOn>2024-04-17T16:55:30.773-04:00</ChangedOn>
          <ExternalMESSyncRequired>false</ExternalMESSyncRequired>
          <CNCustomsBOM>false</CNCustomsBOM>
          <ProcessMfgID></ProcessMfgID>
          <ProcessMfgType></ProcessMfgType>
          <ProcessMfgDescription></ProcessMfgDescription>
          <UseAdvancedStaging>false</UseAdvancedStaging>
          <ProcessMfgLastGroupID></ProcessMfgLastGroupID>
          <DisableApproved>false</DisableApproved>
          <ECOGroup></ECOGroup>
          <HasCoParts>false</HasCoParts>
          <ParentAltMethodDesc></ParentAltMethodDesc>
          <ParentPartNum></ParentPartNum>
          <ParentRevisionNum></ParentRevisionNum>
          <ProdCode></ProdCode>
          <RevStatusAsOfDate>0</RevStatusAsOfDate>
          <SpecHedDescription></SpecHedDescription>
          <vQty>0.00000000</vQty>
          <Class></Class>
          <NonStock>false</NonStock>
          <IsRootNode>false</IsRootNode>
          <EngineeringApproved>false</EngineeringApproved>
          <BitFlag>8</BitFlag>
          <InspPlanDescription></InspPlanDescription>
          <PartDescriptionTrackDimension>false</PartDescriptionTrackDimension>
          <PartDescriptionSellingFactor>1.00000000</PartDescriptionSellingFactor>
          <PartDescriptionPartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartDescriptionPartDescription>
          <PartDescriptionIUM>FT</PartDescriptionIUM>
          <PartDescriptionTrackLots>false</PartDescriptionTrackLots>
          <PartDescriptionPricePerCode>E</PartDescriptionPricePerCode>
          <PartDescriptionSalesUM>FT</PartDescriptionSalesUM>
          <PartDescriptionTrackSerialNum>false</PartDescriptionTrackSerialNum>
          <PartDescriptionTypeCode>P</PartDescriptionTypeCode>
          <PcStatusConfigType></PcStatusConfigType>
          <PlantName>ELECTRI-CORD MFG - MN PLANT</PlantName>
          <RoughCutParamDescription></RoughCutParamDescription>
          <RowMod>U</RowMod>
          <CheckBox01>true</CheckBox01>
          <CheckBox02>false</CheckBox02>
          <CheckBox03>false</CheckBox03>
          <ShortChar06></ShortChar06>
          <PPAP_c>false</PPAP_c>
          <GoldenSample_c>false</GoldenSample_c>
          <JobPrefix_c>FRP</JobPrefix_c>
          <UD_SysRevID>AAAAAM0b4Xs=</UD_SysRevID>
        </PartRev>
        <PartCOPart>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <RevisionNum>-</RevisionNum>
          <CoPartNum>10.1761</CoPartNum>
          <CoRevisionNum>-</CoRevisionNum>
          <PartsPerOp>1</PartsPerOp>
          <LbrCostBase>1</LbrCostBase>
          <MtlCostBase>1</MtlCostBase>
          <PartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartDescription>
          <IUM>FT</IUM>
          <AltMethod></AltMethod>
          <PreventSugg>false</PreventSugg>
          <SysRevID>3441156477</SysRevID>
          <SysRowID>13687c28-5ea7-4252-9a53-97ece7b675b2</SysRowID>
          <PrimaryCost>false</PrimaryCost>
          <ProcessMfgID></ProcessMfgID>
          <EnablePreventSugg>false</EnablePreventSugg>
          <PartMasterPart>false</PartMasterPart>
          <ProcessMode></ProcessMode>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartCOPart>
        <PartWhse>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <WarehouseCode>RAW</WarehouseCode>
          <DemandQty>0.00000000</DemandQty>
          <ReservedQty>0.00000000</ReservedQty>
          <AllocatedQty>0.00000000</AllocatedQty>
          <PickingQty>0.00000000</PickingQty>
          <PickedQty>0.00000000</PickedQty>
          <OnHandQty>0.00000000</OnHandQty>
          <NonNettableQty>0.00000000</NonNettableQty>
          <BuyToOrderQty>0.00000000</BuyToOrderQty>
          <SalesDemandQty>0.00000000</SalesDemandQty>
          <SalesReservedQty>0.00000000</SalesReservedQty>
          <SalesAllocatedQty>0.00000000</SalesAllocatedQty>
          <SalesPickingQty>0.00000000</SalesPickingQty>
          <SalesPickedQty>0.00000000</SalesPickedQty>
          <JobDemandQty>0.00000000</JobDemandQty>
          <JobReservedQty>0.00000000</JobReservedQty>
          <JobAllocatedQty>0.00000000</JobAllocatedQty>
          <JobPickingQty>0.00000000</JobPickingQty>
          <JobPickedQty>0.00000000</JobPickedQty>
          <UnfirmJobDemandQty>0.00000000</UnfirmJobDemandQty>
          <TFOrdDemandQty>0.00000000</TFOrdDemandQty>
          <TFOrdReservedQty>0.00000000</TFOrdReservedQty>
          <TFOrdAllocatedQty>0.00000000</TFOrdAllocatedQty>
          <TFOrdPickingQty>0.00000000</TFOrdPickingQty>
          <TFOrdPickedQty>0.00000000</TFOrdPickedQty>
          <KBCode></KBCode>
          <MinimumQty>0.00000000</MinimumQty>
          <MaximumQty>0.00000000</MaximumQty>
          <SafetyQty>0.00000000</SafetyQty>
          <KBPONUM>0</KBPONUM>
          <KBPOLine>0</KBPOLine>
          <KBWarehouseCode></KBWarehouseCode>
          <KBBinNum></KBBinNum>
          <KBPlant></KBPlant>
          <KBQty>0.00000000</KBQty>
          <PcntTolerance>0.00</PcntTolerance>
          <CalcPcnt>false</CalcPcnt>
          <CalcQty>false</CalcQty>
          <CalcValue>false</CalcValue>
          <QtyAdjTolerance>0.00000000</QtyAdjTolerance>
          <CalcQtyAdj>false</CalcQtyAdj>
          <MinAbc></MinAbc>
          <SystemAbc>C</SystemAbc>
          <ManualABC>false</ManualABC>
          <LastCCDate>2021-05-22T00:00:00-04:00</LastCCDate>
          <OvrrideCountFreq>false</OvrrideCountFreq>
          <CountFreq>0</CountFreq>
          <QtyTolerance>0</QtyTolerance>
          <ValueTolerance>0</ValueTolerance>
          <SysRevID>2173027525</SysRevID>
          <SysRowID>f300f95b-4bca-1d81-e211-07ef0cc42998</SysRowID>
          <Plant>MfgSys</Plant>
          <DefaultWhse>true</DefaultWhse>
          <PrimBinNum></PrimBinNum>
          <TotalDemand>0.00000000</TotalDemand>
          <PrimBinNumDescription></PrimBinNumDescription>
          <KBActionCode></KBActionCode>
          <KBActionDesc></KBActionDesc>
          <PlantOwner>MfgSys</PlantOwner>
          <MaxQtyUOM>FT</MaxQtyUOM>
          <MinQtyUOM>FT</MinQtyUOM>
          <SafetyQtyUOM>FT</SafetyQtyUOM>
          <IUM></IUM>
          <BitFlag>0</BitFlag>
          <KBBinNumDescription></KBBinNumDescription>
          <KBCodeKBActionCode></KBCodeKBActionCode>
          <KBCodeKBDescription></KBCodeKBDescription>
          <KBPlantName></KBPlantName>
          <KBWarehouseCodeDescription></KBWarehouseCodeDescription>
          <PartNumIUM>FT</PartNumIUM>
          <PartNumPricePerCode>E</PartNumPricePerCode>
          <PartNumTrackSerialNum>false</PartNumTrackSerialNum>
          <PartNumSalesUM>FT</PartNumSalesUM>
          <PartNumSellingFactor>1.00000000</PartNumSellingFactor>
          <PartNumTrackLots>false</PartNumTrackLots>
          <PartNumPartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartNumPartDescription>
          <PartNumTrackDimension>false</PartNumTrackDimension>
          <WarehouseDescription>RAW MATERIAL</WarehouseDescription>
          <RowMod></RowMod>
        </PartWhse>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>FT</UOMCode>
          <ConvFactor>12.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>true</TrackOnHand>
          <NetVolume>0.00000</NetVolume>
          <NetVolumeUOM>FZ</NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>16262168</SysRevID>
          <SysRowID>f300f95b-4bca-1d81-e211-07efb64a2b98</SysRowID>
          <ConvFromUOM>1 FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 12.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>FOOT</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>25PER</UOMCode>
          <ConvFactor>300.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>9f879584-70ec-424d-9a95-00b7a0a4074f</SysRowID>
          <ConvFromUOM>1 25PER</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 300.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>25 FEET PER BOX</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>IN</UOMCode>
          <ConvFactor>1.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>bbe1a5fc-a3a6-dc9a-df11-0310bbf4188c</SysRowID>
          <ConvFromUOM>1 IN</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 1.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>INCHES</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>M</UOMCode>
          <ConvFactor>39.3701000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>803c49c6-b6c7-6aa1-e211-e200e66d498c</SysRowID>
          <ConvFromUOM>1 M</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 39.3701000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>METER</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>R100FT</UOMCode>
          <ConvFactor>1200.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>f56de3bb-7bb7-829e-e211-cc01774f108a</SysRowID>
          <ConvFromUOM>1 R100FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 1200.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>100 FOOT ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL18YD</UOMCode>
          <ConvFactor>648.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>ee996ea1-27a7-b796-e111-9ffe8360e5fa</SysRowID>
          <ConvFromUOM>1 RL18YD</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 648.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>18 YARD ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL33FT</UOMCode>
          <ConvFactor>396.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>832b8a79-bdbd-ecac-e211-cc011891cfb3</SysRowID>
          <ConvFromUOM>1 RL33FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 396.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>33 FOOT ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL36YD</UOMCode>
          <ConvFactor>1296.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>8de39d3f-c864-0f83-e211-840d5cedaf9c</SysRowID>
          <ConvFromUOM>1 RL36YD</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 1296.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>36 YARD ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL50FT</UOMCode>
          <ConvFactor>600.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>7d591cde-c592-429b-8402-4f9057a3a443</SysRowID>
          <ConvFromUOM>1 RL50FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 600.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>50 FOOT ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL60FT</UOMCode>
          <ConvFactor>720.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>e462213a-5203-49fa-8094-0a7c50bd6cb9</SysRowID>
          <ConvFromUOM>1 RL60FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 720.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>60 FOOT ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL60YD</UOMCode>
          <ConvFactor>2160.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>e70b631d-1631-4c8a-e011-cfc19b79c1ea</SysRowID>
          <ConvFromUOM>1 RL60YD</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 2160.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>60 YARD ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL66FT</UOMCode>
          <ConvFactor>792.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>82a8546c-7912-fc88-e311-d58210f0d02d</SysRowID>
          <ConvFromUOM>1 RL66FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 792.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>66 FOOT ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>ST48IN</UOMCode>
          <ConvFactor>48.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>c137853b-77ea-f781-e111-7301695d5180</SysRowID>
          <ConvFromUOM>1 ST48IN</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 48.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>48 INCH STICK</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>TQ</UOMCode>
          <ConvFactor>12000.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>bbe1a5fc-a3a6-dc9a-df11-0310a252b6cf</SysRowID>
          <ConvFromUOM>1 TQ</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 12000.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>THOUSAND FEET</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>YD</UOMCode>
          <ConvFactor>36.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>bbe1a5fc-a3a6-dc9a-df11-03102b34dbb0</SysRowID>
          <ConvFromUOM>1 YD</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 36.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>YARD</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
      </PartDataSet>
    </parameter>
    <parameter name="CallContext" type="Ice.Bpm.Context.ContextDataSet">
      <ContextDataSet xmlns="http://www.epicor.com/Ice/300/Bpm/Context">
        <BpmData>
          <SysRowID>00000000-0000-0000-0000-000000000000</SysRowID>
        </BpmData>
      </ContextDataSet>
    </parameter>
  </parameters>
  <paramDataSetChanges>
    <paramDataSet name="ds" useDataSetNbr="0">
      <changedValue tableName="PartRev" rowState="Modified" rowNum="0" colName="Approved"><![CDATA[True]]></changedValue>
      <changedValue tableName="PartRev" rowState="Modified" rowNum="0" colName="RowMod"><![CDATA[U]]></changedValue>
      <changedValue tableName="PartRev" rowState="Modified" rowNum="0" colName="UD_SysRevID"><![CDATA[System.Byte[]]]></changedValue>
    </paramDataSet>
  </paramDataSetChanges>
</tracePacket>

Max_Delgado · April 17, 2024, 5:54pm

<tracePacket>
  <businessObject>Erp.Proxy.BO.PartImpl</businessObject>
  <methodName>GetNewPartAudit</methodName>
  <appServerUri>https://epicor2023.electri-cord.local/ERP11Test/</appServerUri>
  <returnType>System.Void</returnType>
  <localTime>4/17/2024 13:04:07:1060538 PM</localTime>
  <threadID>1</threadID>
  <correlationId>086530a7-8647-40f2-8569-034b4c104ebb</correlationId>
  <executionTime total="25" roundTrip="19" channel="0" bpm="0" bpmDataForm="0" other="6" />
  <retries>0</retries>
  <parameters>
    <parameter name="ds" type="Erp.BO.PartDataSet">
      <PartDataSet xmlns="http://www.epicor.com/Ice/300/BO/Part/Part">
        <Part>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <SearchWord>1/0 AWG</SearchWord>
          <PartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartDescription>
          <ClassID>WIRE</ClassID>
          <IUM>FT</IUM>
          <PUM>FT</PUM>
          <TypeCode>P</TypeCode>
          <NonStock>false</NonStock>
          <PurchasingFactor>1.0000</PurchasingFactor>
          <UnitPrice>0.00000</UnitPrice>
          <PricePerCode>E</PricePerCode>
          <InternalUnitPrice>0.00000</InternalUnitPrice>
          <InternalPricePerCode>E</InternalPricePerCode>
          <ProdCode>OTHER</ProdCode>
          <MfgComment></MfgComment>
          <PurComment></PurComment>
          <CostMethod>S</CostMethod>
          <UserChar1></UserChar1>
          <UserChar2></UserChar2>
          <UserChar3></UserChar3>
          <UserChar4></UserChar4>
          <UserDecimal1>0.00</UserDecimal1>
          <UserDecimal2>0.00</UserDecimal2>
          <UserDecimal3>0.00000</UserDecimal3>
          <UserDecimal4>0.00000</UserDecimal4>
          <UserInteger1>0</UserInteger1>
          <UserInteger2>0</UserInteger2>
          <TaxCatID></TaxCatID>
          <InActive>false</InActive>
          <LowLevelCode>0</LowLevelCode>
          <Method>false</Method>
          <TrackLots>false</TrackLots>
          <TrackDimension>false</TrackDimension>
          <DefaultDim></DefaultDim>
          <TrackSerialNum>false</TrackSerialNum>
          <CommodityCode></CommodityCode>
          <WarrantyCode></WarrantyCode>
          <PhantomBOM>false</PhantomBOM>
          <SalesUM>FT</SalesUM>
          <SellingFactor>1.00000000</SellingFactor>
          <MtlBurRate>0.00000</MtlBurRate>
          <NetWeight>0.00000</NetWeight>
          <UsePartRev>true</UsePartRev>
          <PartsPerContainer>0</PartsPerContainer>
          <PartLength>0.00000</PartLength>
          <PartWidth>0.00000</PartWidth>
          <PartHeight>0.00000</PartHeight>
          <LotShelfLife>0</LotShelfLife>
          <WebPart>false</WebPart>
          <RunOut>false</RunOut>
          <SubPart></SubPart>
          <Diameter>0.00000</Diameter>
          <Gravity>0.00000</Gravity>
          <OnHold>false</OnHold>
          <OnHoldReasonCode></OnHoldReasonCode>
          <AnalysisCode></AnalysisCode>
          <GlobalPart>true</GlobalPart>
          <MtlAnalysisCode></MtlAnalysisCode>
          <GlobalLock>false</GlobalLock>
          <ISSuppUnitsFactor>1.00000000</ISSuppUnitsFactor>
          <PDMObjID></PDMObjID>
          <ImageFileName></ImageFileName>
          <ISOrigCountry>0</ISOrigCountry>
          <SNPrefix></SNPrefix>
          <SNFormat></SNFormat>
          <SNBaseDataType></SNBaseDataType>
          <Constrained>true</Constrained>
          <UPCCode1></UPCCode1>
          <UPCCode2></UPCCode2>
          <UPCCode3></UPCCode3>
          <EDICode></EDICode>
          <WebInStock>false</WebInStock>
          <ConsolidatedPurchasing>false</ConsolidatedPurchasing>
          <PurchasingFactorDirection>D</PurchasingFactorDirection>
          <SellingFactorDirection>D</SellingFactorDirection>
          <RecDocReq>false</RecDocReq>
          <MDPV>0</MDPV>
          <ShipDocReq>false</ShipDocReq>
          <ReturnableContainer></ReturnableContainer>
          <NetVolume>0.00000</NetVolume>
          <QtyBearing>true</QtyBearing>
          <NAFTAOrigCountry></NAFTAOrigCountry>
          <NAFTAProd></NAFTAProd>
          <NAFTAPref></NAFTAPref>
          <ExpLicType></ExpLicType>
          <ExpLicNumber></ExpLicNumber>
          <ECCNNumber></ECCNNumber>
          <AESExp></AESExp>
          <HTS></HTS>
          <UseHTSDesc>false</UseHTSDesc>
          <SchedBcode></SchedBcode>
          <HazItem>false</HazItem>
          <HazTechName></HazTechName>
          <HazClass></HazClass>
          <HazSub></HazSub>
          <HazGvrnmtID></HazGvrnmtID>
          <HazPackInstr></HazPackInstr>
          <RevChargeMethod></RevChargeMethod>
          <RCUnderThreshold>0.000</RCUnderThreshold>
          <RCOverThreshold>0.000</RCOverThreshold>
          <OwnershipStatus></OwnershipStatus>
          <UOMClassID>LENGTH</UOMClassID>
          <SNMask></SNMask>
          <SNMaskExample></SNMaskExample>
          <SNMaskSuffix></SNMaskSuffix>
          <SNMaskPrefix></SNMaskPrefix>
          <SNLastUsedSeq></SNLastUsedSeq>
          <UseMaskSeq>false</UseMaskSeq>
          <NetWeightUOM>OZ</NetWeightUOM>
          <NetVolumeUOM>FZ</NetVolumeUOM>
          <LotBatch>false</LotBatch>
          <LotMfgBatch>false</LotMfgBatch>
          <LotMfgLot>false</LotMfgLot>
          <LotHeat>false</LotHeat>
          <LotFirmware>false</LotFirmware>
          <LotBeforeDt>false</LotBeforeDt>
          <LotMfgDt>false</LotMfgDt>
          <LotCureDt>false</LotCureDt>
          <LotExpDt>false</LotExpDt>
          <LotPrefix></LotPrefix>
          <LotUseGlobalSeq>false</LotUseGlobalSeq>
          <LotSeqID></LotSeqID>
          <LotNxtNum>1</LotNxtNum>
          <LotDigits>0</LotDigits>
          <LotLeadingZeros>false</LotLeadingZeros>
          <LotAppendDate></LotAppendDate>
          <BuyToOrder>false</BuyToOrder>
          <DropShip>false</DropShip>
          <IsConfigured>false</IsConfigured>
          <ExtConfig>false</ExtConfig>
          <RefCategory></RefCategory>
          <CSFCJ5>false</CSFCJ5>
          <CSFLMW>false</CSFLMW>
          <GrossWeight>0.00000</GrossWeight>
          <GrossWeightUOM>OZ</GrossWeightUOM>
          <BasePartNum></BasePartNum>
          <FSAssetClassCode></FSAssetClassCode>
          <FSSalesUnitPrice>0.00000</FSSalesUnitPrice>
          <FSPricePerCode>E</FSPricePerCode>
          <RcvInspectionReq>false</RcvInspectionReq>
          <EstimateID></EstimateID>
          <EstimateOrPlan></EstimateOrPlan>
          <DiffPrc2PrchUOM>false</DiffPrc2PrchUOM>
          <DupOnJobCrt>false</DupOnJobCrt>
          <PricingFactor>0.00000</PricingFactor>
          <PricingUOM></PricingUOM>
          <MobilePart>true</MobilePart>
          <SysRevID>595291056</SysRevID>
          <SysRowID>f300f95b-4bca-1d81-e211-07ef40ef2798</SysRowID>
          <AGUseGoodMark>false</AGUseGoodMark>
          <AGProductMark>false</AGProductMark>
          <ISRegion></ISRegion>
          <INChapterID></INChapterID>
          <PESUNATType></PESUNATType>
          <PESUNATUOM></PESUNATUOM>
          <DEIsServices>false</DEIsServices>
          <DEIsSecurityFinancialDerivative>false</DEIsSecurityFinancialDerivative>
          <DEInternationalSecuritiesID></DEInternationalSecuritiesID>
          <LinkToContract>false</LinkToContract>
          <DEIsInvestment>false</DEIsInvestment>
          <DEPayStatCode>0</DEPayStatCode>
          <DEDenomination></DEDenomination>
          <PartLengthWidthHeightUM></PartLengthWidthHeightUM>
          <DiameterUM></DiameterUM>
          <DiameterInside>0.00000</DiameterInside>
          <DiameterOutside>0.00000</DiameterOutside>
          <ThicknessUM></ThicknessUM>
          <Thickness>0.00000</Thickness>
          <ThicknessMax>0.00000</ThicknessMax>
          <Durometer></Durometer>
          <Specification></Specification>
          <EngineeringAlert></EngineeringAlert>
          <Condition></Condition>
          <IsCompliant>false</IsCompliant>
          <IsRestricted>false</IsRestricted>
          <IsSafetyItem>false</IsSafetyItem>
          <CommercialBrand></CommercialBrand>
          <CommercialSubBrand></CommercialSubBrand>
          <CommercialCategory></CommercialCategory>
          <CommercialSubCategory></CommercialSubCategory>
          <CommercialStyle></CommercialStyle>
          <CommercialSize1></CommercialSize1>
          <CommercialSize2></CommercialSize2>
          <CommercialColor></CommercialColor>
          <IsGiftCard>false</IsGiftCard>
          <PhotoFile></PhotoFile>
          <PartPhotoExists>false</PartPhotoExists>
          <CommentText></CommentText>
          <PartSpecificPackingUOM>false</PartSpecificPackingUOM>
          <ImageID></ImageID>
          <CNSpecification></CNSpecification>
          <SyncToExternalCRM>false</SyncToExternalCRM>
          <ExternalCRMPartID></ExternalCRMPartID>
          <ExternalCRMSyncRequired>false</ExternalCRMSyncRequired>
          <PESUNATTypeCode></PESUNATTypeCode>
          <PESUNATUOMCode></PESUNATUOMCode>
          <CNCodeVersion></CNCodeVersion>
          <CNTaxCategoryCode></CNTaxCategoryCode>
          <CNHasPreferentialTreatment>false</CNHasPreferentialTreatment>
          <CNPreferentialTreatmentContent></CNPreferentialTreatmentContent>
          <CNZeroTaxRateMark></CNZeroTaxRateMark>
          <SubLevelCode>0</SubLevelCode>
          <CreatedBy></CreatedBy>
          <AttBatch>N</AttBatch>
          <AttMfgBatch>N</AttMfgBatch>
          <AttMfgLot>N</AttMfgLot>
          <AttHeat>N</AttHeat>
          <AttFirmware>N</AttFirmware>
          <AttBeforeDt>N</AttBeforeDt>
          <AttMfgDt>N</AttMfgDt>
          <AttCureDt>N</AttCureDt>
          <AttExpDt>N</AttExpDt>
          <DeferManualEntry>false</DeferManualEntry>
          <DeferPurchaseReceipt>false</DeferPurchaseReceipt>
          <DeferJobReceipt>false</DeferJobReceipt>
          <DeferInspection>false</DeferInspection>
          <DeferQtyAdjustment>false</DeferQtyAdjustment>
          <DeferInventoryMove>false</DeferInventoryMove>
          <DeferShipments>false</DeferShipments>
          <DeferInventoryCounts>false</DeferInventoryCounts>
          <DeferAssetDisposal>false</DeferAssetDisposal>
          <DeferReturnMaterials>false</DeferReturnMaterials>
          <MXProdServCode></MXProdServCode>
          <MXCustomsDuty></MXCustomsDuty>
          <SendToFSA>false</SendToFSA>
          <ExternalMESSyncRequired>false</ExternalMESSyncRequired>
          <FSAItem>false</FSAItem>
          <FSAEquipment>false</FSAEquipment>
          <BOLClass></BOLClass>
          <FairMarketValue>0.00000</FairMarketValue>
          <SAFTProdCategory></SAFTProdCategory>
          <AttrClassID></AttrClassID>
          <LocationIDNumReq>false</LocationIDNumReq>
          <LocationTrackInv>false</LocationTrackInv>
          <LocationMtlView>false</LocationMtlView>
          <LCNRVReporting>false</LCNRVReporting>
          <LCNRVEstimatedUnitPrice>0.000</LCNRVEstimatedUnitPrice>
          <MXCustomsUMFrom></MXCustomsUMFrom>
          <LocationFormatID></LocationFormatID>
          <IsServices>false</IsServices>
          <PEDetrGoodServiceCode></PEDetrGoodServiceCode>
          <PEProductServiceCode></PEProductServiceCode>
          <DualUOMClassID></DualUOMClassID>
          <CNProductName></CNProductName>
          <CNWeight>0.00000</CNWeight>
          <CNWeightUOM></CNWeightUOM>
          <CNBonded>false</CNBonded>
          <TrackInventoryAttributes>false</TrackInventoryAttributes>
          <DefaultAttributeSetID>0</DefaultAttributeSetID>
          <AttISOrigCountry>N</AttISOrigCountry>
          <ExternalSchemeID></ExternalSchemeID>
          <ExternalID></ExternalID>
          <CommoditySchemeID></CommoditySchemeID>
          <CommoditySchemeVersion></CommoditySchemeVersion>
          <TrackInventoryByRevision>false</TrackInventoryByRevision>
          <PlanningByRevision>false</PlanningByRevision>
          <CountryNumDescription></CountryNumDescription>
          <EnableExpressCheckOut>false</EnableExpressCheckOut>
          <EnableGlobalLock>false</EnableGlobalLock>
          <EnableGlobalPart>true</EnableGlobalPart>
          <EnableInActive>true</EnableInActive>
          <EnableIUM>false</EnableIUM>
          <EnableRevCharge>false</EnableRevCharge>
          <EnableSerialNum>false</EnableSerialNum>
          <EnableTrackSerialNum>true</EnableTrackSerialNum>
          <EnableUOMClass>false</EnableUOMClass>
          <ExtCoExist>true</ExtCoExist>
          <FSAInstallationCost>0.00000</FSAInstallationCost>
          <FSAInstallationRequired>false</FSAInstallationRequired>
          <FSAInstallationType></FSAInstallationType>
          <FSAInstTypeDesc></FSAInstTypeDesc>
          <GlbFlag>true</GlbFlag>
          <GlbLink></GlbLink>
          <GlbTableAllowUpdTrackDim>false</GlbTableAllowUpdTrackDim>
          <GlbTableAllowUpdTrackLots>false</GlbTableAllowUpdTrackLots>
          <GlbTableAllowUpdTrackSerial>false</GlbTableAllowUpdTrackSerial>
          <HasOnHandQty>false</HasOnHandQty>
          <IsComponent>false</IsComponent>
          <IsCoPart>false</IsCoPart>
          <ISOrigCountryNum>0</ISOrigCountryNum>
          <NextGeneratedLotNum></NextGeneratedLotNum>
          <PEDetrGoodServiceCodeDesc></PEDetrGoodServiceCodeDesc>
          <PEProductServiceCodeDesc></PEProductServiceCodeDesc>
          <PLM>false</PLM>
          <PLMEnabled>false</PLMEnabled>
          <Revision>false</Revision>
          <SalesUMDisp>FT</SalesUMDisp>
          <SNLeadingZeros>false</SNLeadingZeros>
          <SNMaskPrefixLength>0</SNMaskPrefixLength>
          <SNMaskSuffixLength>0</SNMaskSuffixLength>
          <SNNumODigits>0</SNNumODigits>
          <UpdatePartPlant>false</UpdatePartPlant>
          <UpdateSNPartPlant>false</UpdateSNPartPlant>
          <COASegReferences></COASegReferences>
          <HasMRPPlanningAttribute>false</HasMRPPlanningAttribute>
          <UpdatePartPlantOverride>false</UpdatePartPlantOverride>
          <DEPayStatCodeDescr></DEPayStatCodeDescr>
          <DEDenominationDescr></DEDenominationDescr>
          <BitFlag>8</BitFlag>
          <AnalysisCdDescription></AnalysisCdDescription>
          <ClassDescription>WIRE</ClassDescription>
          <CommodityCodeSuppUnitsUOM></CommodityCodeSuppUnitsUOM>
          <CommodityCodeDescription></CommodityCodeDescription>
          <CompanySendToFSA>false</CompanySendToFSA>
          <DualUOMClassIDDescription></DualUOMClassIDDescription>
          <DynAttrValueSetShortDescription></DynAttrValueSetShortDescription>
          <DynAttrValueSetDescription></DynAttrValueSetDescription>
          <FSAssetClassCodeFSAssetClassDesc></FSAssetClassCodeFSAssetClassDesc>
          <Mtl_AnalysisCdDescription></Mtl_AnalysisCdDescription>
          <MXProdServCodeDesc></MXProdServCodeDesc>
          <OnHoldReasonCodeDescription></OnHoldReasonCodeDescription>
          <ProdCodeDescription>OTHER</ProdCodeDescription>
          <RefCategoryDescription></RefCategoryDescription>
          <SerialMaskMaskType>0</SerialMaskMaskType>
          <SerialMaskDescription></SerialMaskDescription>
          <TaxCatIDDescription></TaxCatIDDescription>
          <UOMClassIDDescription>LENGTH</UOMClassIDDescription>
          <WarrantyCodeWarrDescription></WarrantyCodeWarrDescription>
          <XbSystELIEinvoice>true</XbSystELIEinvoice>
          <RowMod></RowMod>
          <Character01></Character01>
          <Character02></Character02>
          <Character03></Character03>
          <Character05></Character05>
          <Number01>0.000000000</Number01>
          <Number05>0.000000000</Number05>
          <Number06>0.000000000</Number06>
          <CheckBox01>true</CheckBox01>
          <CheckBox02>false</CheckBox02>
          <CheckBox03>false</CheckBox03>
          <CheckBox05>false</CheckBox05>
          <CheckBox06>false</CheckBox06>
          <CheckBox07>false</CheckBox07>
          <CheckBox08>false</CheckBox08>
          <ShortChar01></ShortChar01>
          <ShortChar02>Inspect</ShortChar02>
          <ShortChar03></ShortChar03>
          <ShortChar04></ShortChar04>
          <ShortChar05></ShortChar05>
          <ShortChar06></ShortChar06>
          <ShortChar07></ShortChar07>
          <ShortChar08></ShortChar08>
          <ShortChar09></ShortChar09>
          <ShortChar10></ShortChar10>
          <CheckBox04>false</CheckBox04>
          <MinSellQty_c>0.00</MinSellQty_c>
          <Forecasted_c>false</Forecasted_c>
          <ISO13485_c>false</ISO13485_c>
          <TS_16949_c>false</TS_16949_c>
          <CCN_c></CCN_c>
          <ULListed_c>false</ULListed_c>
          <ApprovedMargin_c>0.00</ApprovedMargin_c>
          <TariffCustomer_c>0.00</TariffCustomer_c>
          <TariffSupplier_c>0.00</TariffSupplier_c>
          <Prop65_c>false</Prop65_c>
          <Amortized_c>false</Amortized_c>
          <Commission1_c>0.00000</Commission1_c>
          <Commission2_c>0.00000</Commission2_c>
          <DiscountPct_c>0.00000</DiscountPct_c>
          <CopyExact_c>false</CopyExact_c>
          <CSRMX_c></CSRMX_c>
          <CSRUS_c></CSRUS_c>
          <ASM3CELL_c>false</ASM3CELL_c>
          <Engineer_c></Engineer_c>
          <CopperWeight_c>0.00000</CopperWeight_c>
          <UD_SysRevID>AAAAAAQS4V0=</UD_SysRevID>
        </Part>
        <PartPlant>
          <Company>ECM</Company>
          <Plant>MfgSys</Plant>
          <PartNum>10.1761</PartNum>
          <PrimWhse>RAW</PrimWhse>
          <MinimumQty>0.00000000</MinimumQty>
          <MaximumQty>0.00000000</MaximumQty>
          <SafetyQty>0.00000000</SafetyQty>
          <MinOrderQty>1000.00000000</MinOrderQty>
          <LeadTime>10</LeadTime>
          <VendorNum>20</VendorNum>
          <PurPoint>1</PurPoint>
          <BackFlush>false</BackFlush>
          <MfgLotSize>0.00</MfgLotSize>
          <MinMfgLotSize>0.00</MinMfgLotSize>
          <MaxMfgLotSize>0.00</MaxMfgLotSize>
          <MfgLotMultiple>0.00</MfgLotMultiple>
          <DaysOfSupply>30</DaysOfSupply>
          <ReOrderLevel>false</ReOrderLevel>
          <MRPRecalcNeeded>false</MRPRecalcNeeded>
          <ProcessMRP>true</ProcessMRP>
          <GenerateSugg>true</GenerateSugg>
          <GetFromLocalWhse>false</GetFromLocalWhse>
          <ForecastTime>0</ForecastTime>
          <TransferPlant></TransferPlant>
          <SourceType>P</SourceType>
          <TransferLeadTime>0</TransferLeadTime>
          <PrepTime>0</PrepTime>
          <ReceiveTime>0</ReceiveTime>
          <PlanTimeFence>0</PlanTimeFence>
          <ReschedOutDelta>0</ReschedOutDelta>
          <ReschedInDelta>0</ReschedInDelta>
          <NonStock>false</NonStock>
          <PhantomBOM>false</PhantomBOM>
          <BuyerID></BuyerID>
          <PersonID></PersonID>
          <CostMethod>S</CostMethod>
          <AltMethod></AltMethod>
          <KitTime>0</KitTime>
          <KitAllowUpdate>false</KitAllowUpdate>
          <KitShipComplete>true</KitShipComplete>
          <KitAllowChangeParms>false</KitAllowChangeParms>
          <KitBackFlush>false</KitBackFlush>
          <KitPricing>P</KitPricing>
          <KitPrintCompsPS>true</KitPrintCompsPS>
          <KitPrintCompsInv>true</KitPrintCompsInv>
          <ShortHorizonDays>0</ShortHorizonDays>
          <ShortHorizonMinMfgLotSize>0.00</ShortHorizonMinMfgLotSize>
          <ShortHorizonMaxMfgLotSize>0.00</ShortHorizonMaxMfgLotSize>
          <LimitProdYldRecalc>false</LimitProdYldRecalc>
          <QtyBearing>true</QtyBearing>
          <MRPLastRunDate>2024-03-06T00:00:00-05:00</MRPLastRunDate>
          <MRPLastRunTime>36930</MRPLastRunTime>
          <MRPLastScheduledDate>2024-01-02T00:00:00-05:00</MRPLastScheduledDate>
          <ShortHorizonDaysSupp>0</ShortHorizonDaysSupp>
          <SNMask></SNMask>
          <SNMaskExample></SNMaskExample>
          <SNBaseDataType></SNBaseDataType>
          <SNFormat></SNFormat>
          <SNPrefix></SNPrefix>
          <SNMaskSuffix></SNMaskSuffix>
          <SNMaskPrefix></SNMaskPrefix>
          <SNLastUsedSeq></SNLastUsedSeq>
          <UseMaskSeq>false</UseMaskSeq>
          <BuyToOrder>false</BuyToOrder>
          <DropShip>false</DropShip>
          <PcntTolerance>0.00</PcntTolerance>
          <CalcPcnt>false</CalcPcnt>
          <CalcQty>false</CalcQty>
          <CalcValue>false</CalcValue>
          <QtyAdjTolerance>0.00000000</QtyAdjTolerance>
          <QtyTolerance>0</QtyTolerance>
          <ValueTolerance>0</ValueTolerance>
          <DemandQty>0.00000000</DemandQty>
          <ReservedQty>0.00000000</ReservedQty>
          <AllocatedQty>0.00000000</AllocatedQty>
          <XRefPartNum></XRefPartNum>
          <XRefPartType></XRefPartType>
          <NeverReuseMRPJob>false</NeverReuseMRPJob>
          <DeleteMRPJobs>false</DeleteMRPJobs>
          <TotMfgLeadTimeSys>0</TotMfgLeadTimeSys>
          <TotMfgLeadTimeMnl>0</TotMfgLeadTimeMnl>
          <LvlMfgLeadTimeSys>0</LvlMfgLeadTimeSys>
          <LvlMfgLeadTimeMnl>0</LvlMfgLeadTimeMnl>
          <AutoConsumeStock>false</AutoConsumeStock>
          <StartMinLotQty>false</StartMinLotQty>
          <MinLotLeadTime>0</MinLotLeadTime>
          <MfgLeadTimeMnl>false</MfgLeadTimeMnl>
          <MfgLeadTimeEnteredBy></MfgLeadTimeEnteredBy>
          <MinStartQty>0.00000000</MinStartQty>
          <RawMaterial>false</RawMaterial>
          <MultiLevelCTP>false</MultiLevelCTP>
          <RcvInspectionReq>false</RcvInspectionReq>
          <ConsumeSafety>false</ConsumeSafety>
          <SLTVendorNum>0</SLTVendorNum>
          <SLTPurPoint></SLTPurPoint>
          <ShortLeadTime>0</ShortLeadTime>
          <ExternalMES>false</ExternalMES>
          <SysRevID>3440777672</SysRevID>
          <SysRowID>f300f95b-4bca-1d81-e211-07ef50602a98</SysRowID>
          <UrgentLeadTime>0</UrgentLeadTime>
          <UrgentMinOrdQty>0.00000000</UrgentMinOrdQty>
          <UrgentMultQty>0.00</UrgentMultQty>
          <UrgentPurPoint></UrgentPurPoint>
          <UrgentVendorNum>0</UrgentVendorNum>
          <PartRunMRP>false</PartRunMRP>
          <LinkToContract>false</LinkToContract>
          <MMSExclude>false</MMSExclude>
          <MMSSales>false</MMSSales>
          <MMSIssue>false</MMSIssue>
          <MMSHistory>0</MMSHistory>
          <MMSSafetyFactor>0</MMSSafetyFactor>
          <MMSMaxFactor>0.00</MMSMaxFactor>
          <SavedMinimumQty>0.00000000</SavedMinimumQty>
          <SavedMaximumQty>0.00000000</SavedMaximumQty>
          <SavedSafetyQty>0.00000000</SavedSafetyQty>
          <SavedCalculatedUsageQty>0.00000000</SavedCalculatedUsageQty>
          <ACWPercentage>0</ACWPercentage>
          <ACWDays>0</ACWDays>
          <GenNewPCIDDelaySeconds>0</GenNewPCIDDelaySeconds>
          <GenNewPCIDLimitDays>0</GenNewPCIDLimitDays>
          <TopLvlMfgLeadTimeSys>0</TopLvlMfgLeadTimeSys>
          <TopLvlMfgLeadTimeMnl>0</TopLvlMfgLeadTimeMnl>
          <ActualCostingCategoryID></ActualCostingCategoryID>
          <IncludedIntoAllocationBase>false</IncludedIntoAllocationBase>
          <ForecastDaysBefore>0</ForecastDaysBefore>
          <ForecastDaysAfter>0</ForecastDaysAfter>
          <BaseUOMCode>FT</BaseUOMCode>
          <CalculatedLeadTime>10</CalculatedLeadTime>
          <ExtLeadTime>0</ExtLeadTime>
          <SNNumODigits>0</SNNumODigits>
          <UrgentVendorName></UrgentVendorName>
          <UrgentVendorVendorID></UrgentVendorVendorID>
          <DisableQtyBrng>false</DisableQtyBrng>
          <EnableSerialNum>false</EnableSerialNum>
          <ICTrader>false</ICTrader>
          <InActive>false</InActive>
          <OnHandQty>0</OnHandQty>
          <PlantConfCtrlSerialTracking>1</PlantConfCtrlSerialTracking>
          <SNLeadingZeros>false</SNLeadingZeros>
          <HasOnHandQty>false</HasOnHandQty>
          <IsActCostingAllocEnabled>false</IsActCostingAllocEnabled>
          <MaximumQtyNofP>0.00000000</MaximumQtyNofP>
          <MaxMfgLotSizeNofP>0.00000000</MaxMfgLotSizeNofP>
          <MfgLotMultipleNofP>0.00000000</MfgLotMultipleNofP>
          <MinimumQtyNofP>0.00000000</MinimumQtyNofP>
          <MinMfgLotSizeNofP>0.00000000</MinMfgLotSizeNofP>
          <MinOrderQtyNofP>0.00000000</MinOrderQtyNofP>
          <MinStartQtyNofP>0.00000000</MinStartQtyNofP>
          <QtyDisplayOption></QtyDisplayOption>
          <SafetyQtyNofP>0.00000000</SafetyQtyNofP>
          <ShortHorizonMaxMfgLotSizeNofP>0.00000000</ShortHorizonMaxMfgLotSizeNofP>
          <ShortHorizonMinMfgLotSizeNofP>0.00000000</ShortHorizonMinMfgLotSizeNofP>
          <UrgentMinOrdQtyNofP>0.00000000</UrgentMinOrdQtyNofP>
          <UrgentMultQtyNofP>0.00000000</UrgentMultQtyNofP>
          <BitFlag>8</BitFlag>
          <BuyerIDName></BuyerIDName>
          <PartTrackInventoryAttributes>false</PartTrackInventoryAttributes>
          <PartAttrClassID></PartAttrClassID>
          <PartSellingFactor>1.00000000</PartSellingFactor>
          <PartTrackLots>false</PartTrackLots>
          <PartTrackSerialNum>false</PartTrackSerialNum>
          <PartTrackDimension>false</PartTrackDimension>
          <PartIUM>FT</PartIUM>
          <PartPricePerCode>E</PartPricePerCode>
          <PartPartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartPartDescription>
          <PartSalesUM>FT</PartSalesUM>
          <PersonName></PersonName>
          <PlantName>ELECTRI-CORD MFG - PA PLANT</PlantName>
          <PrimWhseDescription>RAW MATERIAL</PrimWhseDescription>
          <SerialMaskMaskType>0</SerialMaskMaskType>
          <SerialMaskDescription></SerialMaskDescription>
          <TransferPlantName></TransferPlantName>
          <VendorNumAddress1>PO BOX 26157</VendorNumAddress1>
          <VendorNumState>PA</VendorNumState>
          <VendorNumCountry>UNITED STATES</VendorNumCountry>
          <VendorNumCity>COLLEGEVILLE</VendorNumCity>
          <VendorNumCurrencyCode>BASE</VendorNumCurrencyCode>
          <VendorNumDefaultFOB>FOBSHIP</VendorNumDefaultFOB>
          <VendorNumAddress2></VendorNumAddress2>
          <VendorNumZIP>26157</VendorNumZIP>
          <VendorNumTermsCode>N60</VendorNumTermsCode>
          <VendorNumAddress3></VendorNumAddress3>
          <VendorNumName>ALLIED WIRE &amp; CABLE</VendorNumName>
          <VendorNumVendorID>1018</VendorNumVendorID>
          <RowMod></RowMod>
          <Character01></Character01>
          <Character02></Character02>
          <Character03></Character03>
          <Character04></Character04>
          <Character05></Character05>
          <Character06></Character06>
          <Number01>0.000000000</Number01>
          <CheckBox01>false</CheckBox01>
          <ToolingCap_c>0.00</ToolingCap_c>
          <UD_SysRevID>AAAAAAQMCfI=</UD_SysRevID>
        </PartPlant>
        <PartRev>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <RevisionNum>-</RevisionNum>
          <RevShortDesc>Default</RevShortDesc>
          <RevDescription></RevDescription>
          <Approved>true</Approved>
          <ApprovedBy></ApprovedBy>
          <EffectiveDate>2024-04-17T00:00:00-04:00</EffectiveDate>
          <TLRLaborCost>0.00000</TLRLaborCost>
          <TLRBurdenCost>0.00000</TLRBurdenCost>
          <TLRMaterialCost>0.00000</TLRMaterialCost>
          <TLRSubcontractCost>0.00000</TLRSubcontractCost>
          <TLRMtlBurCost>0.00000</TLRMtlBurCost>
          <TLRSetupLaborCost>0.00000</TLRSetupLaborCost>
          <TLRSetupBurdenCost>0.00000</TLRSetupBurdenCost>
          <LLRLaborCost>0.00000</LLRLaborCost>
          <LLRBurdenCost>0.00000</LLRBurdenCost>
          <LLRMaterialCost>0.00000</LLRMaterialCost>
          <LLRSubcontractCost>0.00000</LLRSubcontractCost>
          <LLRMtlBurCost>0.00000</LLRMtlBurCost>
          <LLRSetupLaborCost>0.00000</LLRSetupLaborCost>
          <LLRSetupBurdenCost>0.00000</LLRSetupBurdenCost>
          <DrawNum></DrawNum>
          <ECO></ECO>
          <Method>false</Method>
          <AutoRecOpr>0</AutoRecOpr>
          <FinalOpr>0</FinalOpr>
          <PDMObjID></PDMObjID>
          <Configured>false</Configured>
          <WebConfigured>false</WebConfigured>
          <ShowInputPrice>false</ShowInputPrice>
          <AltMethod></AltMethod>
          <AltMethodDesc></AltMethodDesc>
          <Plant>MN</Plant>
          <ParentAltMethod></ParentAltMethod>
          <UseStaging>false</UseStaging>
          <UseAltRevForParts>false</UseAltRevForParts>
          <OwnershipStatus></OwnershipStatus>
          <ExtConfig>false</ExtConfig>
          <ValRefDes>false</ValRefDes>
          <PcGlobalPart>false</PcGlobalPart>
          <PcEntprsConf>false</PcEntprsConf>
          <GlobalRev>false</GlobalRev>
          <RoughCutCode></RoughCutCode>
          <RMAInspPlan></RMAInspPlan>
          <RMASpecID></RMASpecID>
          <RMASampleSize>0.00000000</RMASampleSize>
          <RMASampleSizePct>0.00</RMASampleSizePct>
          <BasePartNum></BasePartNum>
          <BaseRevisionNum></BaseRevisionNum>
          <ConfigID></ConfigID>
          <RegenConfig>false</RegenConfig>
          <SIValuesGroupSeq>0</SIValuesGroupSeq>
          <SIValuesHeadNum>0</SIValuesHeadNum>
          <ExternalMES>false</ExternalMES>
          <SysRevID>3441156476</SysRevID>
          <SysRowID>cf469999-a5fa-4667-a855-083e04d9fbc3</SysRowID>
          <ProcessMode>S</ProcessMode>
          <DefaultConfigPart>false</DefaultConfigPart>
          <CoPartsReqQty>0.00000000</CoPartsReqQty>
          <MtlCostPct>0.00000</MtlCostPct>
          <LaborCostPct>0.00000</LaborCostPct>
          <CoPartsPerOp>0</CoPartsPerOp>
          <CreatedBy>ComTec</CreatedBy>
          <CreatedOn>2024-04-17T16:55:30.773-04:00</CreatedOn>
          <ChangedBy>ComTec</ChangedBy>
          <ChangedOn>2024-04-17T16:55:30.773-04:00</ChangedOn>
          <ExternalMESSyncRequired>false</ExternalMESSyncRequired>
          <CNCustomsBOM>false</CNCustomsBOM>
          <ProcessMfgID></ProcessMfgID>
          <ProcessMfgType></ProcessMfgType>
          <ProcessMfgDescription></ProcessMfgDescription>
          <UseAdvancedStaging>false</UseAdvancedStaging>
          <ProcessMfgLastGroupID></ProcessMfgLastGroupID>
          <DisableApproved>false</DisableApproved>
          <ECOGroup></ECOGroup>
          <HasCoParts>false</HasCoParts>
          <ParentAltMethodDesc></ParentAltMethodDesc>
          <ParentPartNum></ParentPartNum>
          <ParentRevisionNum></ParentRevisionNum>
          <ProdCode></ProdCode>
          <RevStatusAsOfDate>0</RevStatusAsOfDate>
          <SpecHedDescription></SpecHedDescription>
          <vQty>0.00000000</vQty>
          <Class></Class>
          <NonStock>false</NonStock>
          <IsRootNode>false</IsRootNode>
          <EngineeringApproved>false</EngineeringApproved>
          <BitFlag>8</BitFlag>
          <InspPlanDescription></InspPlanDescription>
          <PartDescriptionTrackDimension>false</PartDescriptionTrackDimension>
          <PartDescriptionSellingFactor>1.00000000</PartDescriptionSellingFactor>
          <PartDescriptionPartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartDescriptionPartDescription>
          <PartDescriptionIUM>FT</PartDescriptionIUM>
          <PartDescriptionTrackLots>false</PartDescriptionTrackLots>
          <PartDescriptionPricePerCode>E</PartDescriptionPricePerCode>
          <PartDescriptionSalesUM>FT</PartDescriptionSalesUM>
          <PartDescriptionTrackSerialNum>false</PartDescriptionTrackSerialNum>
          <PartDescriptionTypeCode>P</PartDescriptionTypeCode>
          <PcStatusConfigType></PcStatusConfigType>
          <PlantName>ELECTRI-CORD MFG - MN PLANT</PlantName>
          <RoughCutParamDescription></RoughCutParamDescription>
          <RowMod>U</RowMod>
          <CheckBox01>true</CheckBox01>
          <CheckBox02>false</CheckBox02>
          <CheckBox03>false</CheckBox03>
          <ShortChar06></ShortChar06>
          <PPAP_c>false</PPAP_c>
          <GoldenSample_c>false</GoldenSample_c>
          <JobPrefix_c>FRP</JobPrefix_c>
          <UD_SysRevID>AAAAAM0b4Xs=</UD_SysRevID>
        </PartRev>
        <PartAudit>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <RevisionNum>-</RevisionNum>
          <ChangeDate>2024-04-17T00:00:00-04:00</ChangeDate>
          <ChangeTime>0</ChangeTime>
          <ChangedBy></ChangedBy>
          <ChangeDescription></ChangeDescription>
          <AltMethod></AltMethod>
          <SysRevID>0</SysRevID>
          <SysRowID>00000000-0000-0000-0000-000000000000</SysRowID>
          <ProcessMfgID></ProcessMfgID>
          <DspChangeTime></DspChangeTime>
          <BitFlag>0</BitFlag>
          <PartNumTrackDimension>false</PartNumTrackDimension>
          <PartNumTrackLots>false</PartNumTrackLots>
          <PartNumPartDescription></PartNumPartDescription>
          <PartNumPricePerCode>E</PartNumPricePerCode>
          <PartNumTrackSerialNum>false</PartNumTrackSerialNum>
          <PartNumIUM></PartNumIUM>
          <PartNumSalesUM></PartNumSalesUM>
          <PartNumSellingFactor>1</PartNumSellingFactor>
          <RevisionNumRevShortDesc></RevisionNumRevShortDesc>
          <RevisionNumRevDescription></RevisionNumRevDescription>
          <RowMod>A</RowMod>
        </PartAudit>
        <PartCOPart>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <RevisionNum>-</RevisionNum>
          <CoPartNum>10.1761</CoPartNum>
          <CoRevisionNum>-</CoRevisionNum>
          <PartsPerOp>1</PartsPerOp>
          <LbrCostBase>1</LbrCostBase>
          <MtlCostBase>1</MtlCostBase>
          <PartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartDescription>
          <IUM>FT</IUM>
          <AltMethod></AltMethod>
          <PreventSugg>false</PreventSugg>
          <SysRevID>3441156477</SysRevID>
          <SysRowID>13687c28-5ea7-4252-9a53-97ece7b675b2</SysRowID>
          <PrimaryCost>false</PrimaryCost>
          <ProcessMfgID></ProcessMfgID>
          <EnablePreventSugg>false</EnablePreventSugg>
          <PartMasterPart>false</PartMasterPart>
          <ProcessMode></ProcessMode>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartCOPart>
        <PartWhse>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <WarehouseCode>RAW</WarehouseCode>
          <DemandQty>0.00000000</DemandQty>
          <ReservedQty>0.00000000</ReservedQty>
          <AllocatedQty>0.00000000</AllocatedQty>
          <PickingQty>0.00000000</PickingQty>
          <PickedQty>0.00000000</PickedQty>
          <OnHandQty>0.00000000</OnHandQty>
          <NonNettableQty>0.00000000</NonNettableQty>
          <BuyToOrderQty>0.00000000</BuyToOrderQty>
          <SalesDemandQty>0.00000000</SalesDemandQty>
          <SalesReservedQty>0.00000000</SalesReservedQty>
          <SalesAllocatedQty>0.00000000</SalesAllocatedQty>
          <SalesPickingQty>0.00000000</SalesPickingQty>
          <SalesPickedQty>0.00000000</SalesPickedQty>
          <JobDemandQty>0.00000000</JobDemandQty>
          <JobReservedQty>0.00000000</JobReservedQty>
          <JobAllocatedQty>0.00000000</JobAllocatedQty>
          <JobPickingQty>0.00000000</JobPickingQty>
          <JobPickedQty>0.00000000</JobPickedQty>
          <UnfirmJobDemandQty>0.00000000</UnfirmJobDemandQty>
          <TFOrdDemandQty>0.00000000</TFOrdDemandQty>
          <TFOrdReservedQty>0.00000000</TFOrdReservedQty>
          <TFOrdAllocatedQty>0.00000000</TFOrdAllocatedQty>
          <TFOrdPickingQty>0.00000000</TFOrdPickingQty>
          <TFOrdPickedQty>0.00000000</TFOrdPickedQty>
          <KBCode></KBCode>
          <MinimumQty>0.00000000</MinimumQty>
          <MaximumQty>0.00000000</MaximumQty>
          <SafetyQty>0.00000000</SafetyQty>
          <KBPONUM>0</KBPONUM>
          <KBPOLine>0</KBPOLine>
          <KBWarehouseCode></KBWarehouseCode>
          <KBBinNum></KBBinNum>
          <KBPlant></KBPlant>
          <KBQty>0.00000000</KBQty>
          <PcntTolerance>0.00</PcntTolerance>
          <CalcPcnt>false</CalcPcnt>
          <CalcQty>false</CalcQty>
          <CalcValue>false</CalcValue>
          <QtyAdjTolerance>0.00000000</QtyAdjTolerance>
          <CalcQtyAdj>false</CalcQtyAdj>
          <MinAbc></MinAbc>
          <SystemAbc>C</SystemAbc>
          <ManualABC>false</ManualABC>
          <LastCCDate>2021-05-22T00:00:00-04:00</LastCCDate>
          <OvrrideCountFreq>false</OvrrideCountFreq>
          <CountFreq>0</CountFreq>
          <QtyTolerance>0</QtyTolerance>
          <ValueTolerance>0</ValueTolerance>
          <SysRevID>2173027525</SysRevID>
          <SysRowID>f300f95b-4bca-1d81-e211-07ef0cc42998</SysRowID>
          <Plant>MfgSys</Plant>
          <DefaultWhse>true</DefaultWhse>
          <PrimBinNum></PrimBinNum>
          <TotalDemand>0.00000000</TotalDemand>
          <PrimBinNumDescription></PrimBinNumDescription>
          <KBActionCode></KBActionCode>
          <KBActionDesc></KBActionDesc>
          <PlantOwner>MfgSys</PlantOwner>
          <MaxQtyUOM>FT</MaxQtyUOM>
          <MinQtyUOM>FT</MinQtyUOM>
          <SafetyQtyUOM>FT</SafetyQtyUOM>
          <IUM></IUM>
          <BitFlag>0</BitFlag>
          <KBBinNumDescription></KBBinNumDescription>
          <KBCodeKBActionCode></KBCodeKBActionCode>
          <KBCodeKBDescription></KBCodeKBDescription>
          <KBPlantName></KBPlantName>
          <KBWarehouseCodeDescription></KBWarehouseCodeDescription>
          <PartNumIUM>FT</PartNumIUM>
          <PartNumPricePerCode>E</PartNumPricePerCode>
          <PartNumTrackSerialNum>false</PartNumTrackSerialNum>
          <PartNumSalesUM>FT</PartNumSalesUM>
          <PartNumSellingFactor>1.00000000</PartNumSellingFactor>
          <PartNumTrackLots>false</PartNumTrackLots>
          <PartNumPartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartNumPartDescription>
          <PartNumTrackDimension>false</PartNumTrackDimension>
          <WarehouseDescription>RAW MATERIAL</WarehouseDescription>
          <RowMod></RowMod>
        </PartWhse>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>FT</UOMCode>
          <ConvFactor>12.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>true</TrackOnHand>
          <NetVolume>0.00000</NetVolume>
          <NetVolumeUOM>FZ</NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>16262168</SysRevID>
          <SysRowID>f300f95b-4bca-1d81-e211-07efb64a2b98</SysRowID>
          <ConvFromUOM>1 FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 12.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>FOOT</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>25PER</UOMCode>
          <ConvFactor>300.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>9f879584-70ec-424d-9a95-00b7a0a4074f</SysRowID>
          <ConvFromUOM>1 25PER</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 300.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>25 FEET PER BOX</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>IN</UOMCode>
          <ConvFactor>1.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>bbe1a5fc-a3a6-dc9a-df11-0310bbf4188c</SysRowID>
          <ConvFromUOM>1 IN</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 1.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>INCHES</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>M</UOMCode>
          <ConvFactor>39.3701000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>803c49c6-b6c7-6aa1-e211-e200e66d498c</SysRowID>
          <ConvFromUOM>1 M</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 39.3701000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>METER</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>R100FT</UOMCode>
          <ConvFactor>1200.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>f56de3bb-7bb7-829e-e211-cc01774f108a</SysRowID>
          <ConvFromUOM>1 R100FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 1200.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>100 FOOT ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL18YD</UOMCode>
          <ConvFactor>648.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>ee996ea1-27a7-b796-e111-9ffe8360e5fa</SysRowID>
          <ConvFromUOM>1 RL18YD</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 648.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>18 YARD ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL33FT</UOMCode>
          <ConvFactor>396.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>832b8a79-bdbd-ecac-e211-cc011891cfb3</SysRowID>
          <ConvFromUOM>1 RL33FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 396.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>33 FOOT ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL36YD</UOMCode>
          <ConvFactor>1296.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>8de39d3f-c864-0f83-e211-840d5cedaf9c</SysRowID>
          <ConvFromUOM>1 RL36YD</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 1296.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>36 YARD ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL50FT</UOMCode>
          <ConvFactor>600.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>7d591cde-c592-429b-8402-4f9057a3a443</SysRowID>
          <ConvFromUOM>1 RL50FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 600.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>50 FOOT ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL60FT</UOMCode>
          <ConvFactor>720.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>e462213a-5203-49fa-8094-0a7c50bd6cb9</SysRowID>
          <ConvFromUOM>1 RL60FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 720.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>60 FOOT ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL60YD</UOMCode>
          <ConvFactor>2160.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>e70b631d-1631-4c8a-e011-cfc19b79c1ea</SysRowID>
          <ConvFromUOM>1 RL60YD</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 2160.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>60 YARD ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL66FT</UOMCode>
          <ConvFactor>792.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>82a8546c-7912-fc88-e311-d58210f0d02d</SysRowID>
          <ConvFromUOM>1 RL66FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 792.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>66 FOOT ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>ST48IN</UOMCode>
          <ConvFactor>48.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>c137853b-77ea-f781-e111-7301695d5180</SysRowID>
          <ConvFromUOM>1 ST48IN</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 48.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>48 INCH STICK</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>TQ</UOMCode>
          <ConvFactor>12000.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>bbe1a5fc-a3a6-dc9a-df11-0310a252b6cf</SysRowID>
          <ConvFromUOM>1 TQ</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 12000.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>THOUSAND FEET</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>YD</UOMCode>
          <ConvFactor>36.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>bbe1a5fc-a3a6-dc9a-df11-03102b34dbb0</SysRowID>
          <ConvFromUOM>1 YD</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 36.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>YARD</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
      </PartDataSet>
    </parameter>

Max_Delgado · April 17, 2024, 5:54pm

<parameter name="partNum" type="System.String"><![CDATA[10.1761]]></parameter>
    <parameter name="revisionNum" type="System.String"><![CDATA[-]]></parameter>
    <parameter name="altMethod" type="System.String"><![CDATA[]]></parameter>
    <parameter name="processMfgID" type="System.String"><![CDATA[]]></parameter>
    <parameter name="changeDate" type="System.DateTime"><![CDATA[4/17/2024 12:00:00 AM]]></parameter>
    <parameter name="CallContext" type="Ice.Bpm.Context.ContextDataSet">
      <ContextDataSet xmlns="http://www.epicor.com/Ice/300/Bpm/Context">
        <BpmData>
          <SysRowID>00000000-0000-0000-0000-000000000000</SysRowID>
        </BpmData>
      </ContextDataSet>
    </parameter>
  </parameters>
  <paramDataSetChanges>
    <paramDataSet name="ds" useDataSetNbr="0">
      <changedValue tableName="PartRev" rowState="Modified" rowNum="0" colName="Approved"><![CDATA[True]]></changedValue>
      <changedValue tableName="PartRev" rowState="Modified" rowNum="0" colName="RowMod"><![CDATA[U]]></changedValue>
      <changedValue tableName="PartRev" rowState="Modified" rowNum="0" colName="UD_SysRevID"><![CDATA[System.Byte[]]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="Company"><![CDATA[ECM]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="PartNum"><![CDATA[10.1761]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="RevisionNum"><![CDATA[-]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="ChangeDate"><![CDATA[4/17/2024 12:00:00 AM]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="ChangeTime"><![CDATA[0]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="ChangedBy"><![CDATA[]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="ChangeDescription"><![CDATA[]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="AltMethod"><![CDATA[]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="SysRevID"><![CDATA[0]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="SysRowID"><![CDATA[00000000-0000-0000-0000-000000000000]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="ProcessMfgID"><![CDATA[]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="DspChangeTime"><![CDATA[]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="BitFlag"><![CDATA[0]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="PartNumTrackDimension"><![CDATA[False]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="PartNumTrackLots"><![CDATA[False]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="PartNumPartDescription"><![CDATA[]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="PartNumPricePerCode"><![CDATA[E]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="PartNumTrackSerialNum"><![CDATA[False]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="PartNumIUM"><![CDATA[]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="PartNumSalesUM"><![CDATA[]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="PartNumSellingFactor"><![CDATA[1]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="RevisionNumRevShortDesc"><![CDATA[]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="RevisionNumRevDescription"><![CDATA[]]></changedValue>
      <changedValue tableName="PartAudit" rowState="Added" rowNum="0" colName="RowMod"><![CDATA[A]]></changedValue>
    </paramDataSet>
  </paramDataSetChanges>
</tracePacket>

<tracePacket>
  <businessObject>Erp.Proxy.BO.PartImpl</businessObject>
  <methodName>Update</methodName>
  <appServerUri>https://epicor2023.electri-cord.local/ERP11Test/</appServerUri>
  <returnType>System.Void</returnType>
  <localTime>4/17/2024 13:04:07:1379133 PM</localTime>
  <threadID>1</threadID>
  <correlationId>6467b043-96f8-4f49-b618-44a210e39b2a</correlationId>
  <executionTime total="402" roundTrip="395" channel="0" bpm="0" bpmDataForm="0" other="7" />
  <retries>0</retries>
  <parameters>
    <parameter name="ds" type="Erp.BO.PartDataSet">
      <PartDataSet xmlns="http://www.epicor.com/Ice/300/BO/Part/Part">
        <Part>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <SearchWord>1/0 AWG</SearchWord>
          <PartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartDescription>
          <ClassID>WIRE</ClassID>
          <IUM>FT</IUM>
          <PUM>FT</PUM>
          <TypeCode>P</TypeCode>
          <NonStock>false</NonStock>
          <PurchasingFactor>1</PurchasingFactor>
          <UnitPrice>0</UnitPrice>
          <PricePerCode>E</PricePerCode>
          <InternalUnitPrice>0</InternalUnitPrice>
          <InternalPricePerCode>E</InternalPricePerCode>
          <ProdCode>OTHER</ProdCode>
          <MfgComment></MfgComment>
          <PurComment></PurComment>
          <CostMethod>S</CostMethod>
          <UserChar1></UserChar1>
          <UserChar2></UserChar2>
          <UserChar3></UserChar3>
          <UserChar4></UserChar4>
          <UserDecimal1>0</UserDecimal1>
          <UserDecimal2>0</UserDecimal2>
          <UserDecimal3>0</UserDecimal3>
          <UserDecimal4>0</UserDecimal4>
          <UserInteger1>0</UserInteger1>
          <UserInteger2>0</UserInteger2>
          <TaxCatID></TaxCatID>
          <InActive>false</InActive>
          <LowLevelCode>0</LowLevelCode>
          <Method>false</Method>
          <TrackLots>false</TrackLots>
          <TrackDimension>false</TrackDimension>
          <DefaultDim></DefaultDim>
          <TrackSerialNum>false</TrackSerialNum>
          <CommodityCode></CommodityCode>
          <WarrantyCode></WarrantyCode>
          <PhantomBOM>false</PhantomBOM>
          <SalesUM>FT</SalesUM>
          <SellingFactor>1</SellingFactor>
          <MtlBurRate>0</MtlBurRate>
          <NetWeight>0</NetWeight>
          <UsePartRev>true</UsePartRev>
          <PartsPerContainer>0</PartsPerContainer>
          <PartLength>0</PartLength>
          <PartWidth>0</PartWidth>
          <PartHeight>0</PartHeight>
          <LotShelfLife>0</LotShelfLife>
          <WebPart>false</WebPart>
          <RunOut>false</RunOut>
          <SubPart></SubPart>
          <Diameter>0</Diameter>
          <Gravity>0</Gravity>
          <OnHold>false</OnHold>
          <OnHoldReasonCode></OnHoldReasonCode>
          <AnalysisCode></AnalysisCode>
          <GlobalPart>true</GlobalPart>
          <MtlAnalysisCode></MtlAnalysisCode>
          <GlobalLock>false</GlobalLock>
          <ISSuppUnitsFactor>1</ISSuppUnitsFactor>
          <PDMObjID></PDMObjID>
          <ImageFileName></ImageFileName>
          <ISOrigCountry>0</ISOrigCountry>
          <SNPrefix></SNPrefix>
          <SNFormat></SNFormat>
          <SNBaseDataType></SNBaseDataType>
          <Constrained>true</Constrained>
          <UPCCode1></UPCCode1>
          <UPCCode2></UPCCode2>
          <UPCCode3></UPCCode3>
          <EDICode></EDICode>
          <WebInStock>false</WebInStock>
          <ConsolidatedPurchasing>false</ConsolidatedPurchasing>
          <PurchasingFactorDirection>D</PurchasingFactorDirection>
          <SellingFactorDirection>D</SellingFactorDirection>
          <RecDocReq>false</RecDocReq>
          <MDPV>0</MDPV>
          <ShipDocReq>false</ShipDocReq>
          <ReturnableContainer></ReturnableContainer>
          <NetVolume>0</NetVolume>
          <QtyBearing>true</QtyBearing>
          <NAFTAOrigCountry></NAFTAOrigCountry>
          <NAFTAProd></NAFTAProd>
          <NAFTAPref></NAFTAPref>
          <ExpLicType></ExpLicType>
          <ExpLicNumber></ExpLicNumber>
          <ECCNNumber></ECCNNumber>
          <AESExp></AESExp>
          <HTS></HTS>
          <UseHTSDesc>false</UseHTSDesc>
          <SchedBcode></SchedBcode>
          <HazItem>false</HazItem>
          <HazTechName></HazTechName>
          <HazClass></HazClass>
          <HazSub></HazSub>
          <HazGvrnmtID></HazGvrnmtID>
          <HazPackInstr></HazPackInstr>
          <RevChargeMethod></RevChargeMethod>
          <RCUnderThreshold>0</RCUnderThreshold>
          <RCOverThreshold>0</RCOverThreshold>
          <OwnershipStatus></OwnershipStatus>
          <UOMClassID>LENGTH</UOMClassID>
          <SNMask></SNMask>
          <SNMaskExample></SNMaskExample>
          <SNMaskSuffix></SNMaskSuffix>
          <SNMaskPrefix></SNMaskPrefix>
          <SNLastUsedSeq></SNLastUsedSeq>
          <UseMaskSeq>false</UseMaskSeq>
          <NetWeightUOM>OZ</NetWeightUOM>
          <NetVolumeUOM>FZ</NetVolumeUOM>
          <LotBatch>false</LotBatch>
          <LotMfgBatch>false</LotMfgBatch>
          <LotMfgLot>false</LotMfgLot>
          <LotHeat>false</LotHeat>
          <LotFirmware>false</LotFirmware>
          <LotBeforeDt>false</LotBeforeDt>
          <LotMfgDt>false</LotMfgDt>
          <LotCureDt>false</LotCureDt>
          <LotExpDt>false</LotExpDt>
          <LotPrefix></LotPrefix>
          <LotUseGlobalSeq>false</LotUseGlobalSeq>
          <LotSeqID></LotSeqID>
          <LotNxtNum>1</LotNxtNum>
          <LotDigits>0</LotDigits>
          <LotLeadingZeros>false</LotLeadingZeros>
          <LotAppendDate></LotAppendDate>
          <BuyToOrder>false</BuyToOrder>
          <DropShip>false</DropShip>
          <IsConfigured>false</IsConfigured>
          <ExtConfig>false</ExtConfig>
          <RefCategory></RefCategory>
          <CSFCJ5>false</CSFCJ5>
          <CSFLMW>false</CSFLMW>
          <GrossWeight>0</GrossWeight>
          <GrossWeightUOM>OZ</GrossWeightUOM>
          <BasePartNum></BasePartNum>
          <FSAssetClassCode></FSAssetClassCode>
          <FSSalesUnitPrice>0</FSSalesUnitPrice>
          <FSPricePerCode>E</FSPricePerCode>
          <RcvInspectionReq>false</RcvInspectionReq>
          <EstimateID></EstimateID>
          <EstimateOrPlan></EstimateOrPlan>
          <DiffPrc2PrchUOM>false</DiffPrc2PrchUOM>
          <DupOnJobCrt>false</DupOnJobCrt>
          <PricingFactor>0</PricingFactor>
          <PricingUOM></PricingUOM>
          <MobilePart>true</MobilePart>
          <SysRevID>595291056</SysRevID>
          <SysRowID>f300f95b-4bca-1d81-e211-07ef40ef2798</SysRowID>
          <AGUseGoodMark>false</AGUseGoodMark>
          <AGProductMark>false</AGProductMark>
          <ISRegion></ISRegion>
          <INChapterID></INChapterID>
          <PESUNATType></PESUNATType>
          <PESUNATUOM></PESUNATUOM>
          <DEIsServices>false</DEIsServices>
          <DEIsSecurityFinancialDerivative>false</DEIsSecurityFinancialDerivative>
          <DEInternationalSecuritiesID></DEInternationalSecuritiesID>
          <LinkToContract>false</LinkToContract>
          <DEIsInvestment>false</DEIsInvestment>
          <DEPayStatCode>0</DEPayStatCode>
          <DEDenomination></DEDenomination>
          <PartLengthWidthHeightUM></PartLengthWidthHeightUM>
          <DiameterUM></DiameterUM>
          <DiameterInside>0</DiameterInside>
          <DiameterOutside>0</DiameterOutside>
          <ThicknessUM></ThicknessUM>
          <Thickness>0</Thickness>
          <ThicknessMax>0</ThicknessMax>
          <Durometer></Durometer>
          <Specification></Specification>
          <EngineeringAlert></EngineeringAlert>
          <Condition></Condition>
          <IsCompliant>false</IsCompliant>
          <IsRestricted>false</IsRestricted>
          <IsSafetyItem>false</IsSafetyItem>
          <CommercialBrand></CommercialBrand>
          <CommercialSubBrand></CommercialSubBrand>
          <CommercialCategory></CommercialCategory>
          <CommercialSubCategory></CommercialSubCategory>
          <CommercialStyle></CommercialStyle>
          <CommercialSize1></CommercialSize1>
          <CommercialSize2></CommercialSize2>
          <CommercialColor></CommercialColor>
          <IsGiftCard>false</IsGiftCard>
          <PhotoFile></PhotoFile>
          <PartPhotoExists>false</PartPhotoExists>
          <CommentText></CommentText>
          <PartSpecificPackingUOM>false</PartSpecificPackingUOM>
          <ImageID></ImageID>
          <CNSpecification></CNSpecification>
          <SyncToExternalCRM>false</SyncToExternalCRM>
          <ExternalCRMPartID></ExternalCRMPartID>
          <ExternalCRMSyncRequired>false</ExternalCRMSyncRequired>
          <PESUNATTypeCode></PESUNATTypeCode>
          <PESUNATUOMCode></PESUNATUOMCode>
          <CNCodeVersion></CNCodeVersion>
          <CNTaxCategoryCode></CNTaxCategoryCode>
          <CNHasPreferentialTreatment>false</CNHasPreferentialTreatment>
          <CNPreferentialTreatmentContent></CNPreferentialTreatmentContent>
          <CNZeroTaxRateMark></CNZeroTaxRateMark>
          <SubLevelCode>0</SubLevelCode>
          <CreatedBy></CreatedBy>
          <AttBatch>N</AttBatch>
          <AttMfgBatch>N</AttMfgBatch>
          <AttMfgLot>N</AttMfgLot>
          <AttHeat>N</AttHeat>
          <AttFirmware>N</AttFirmware>
          <AttBeforeDt>N</AttBeforeDt>
          <AttMfgDt>N</AttMfgDt>
          <AttCureDt>N</AttCureDt>
          <AttExpDt>N</AttExpDt>
          <DeferManualEntry>false</DeferManualEntry>
          <DeferPurchaseReceipt>false</DeferPurchaseReceipt>
          <DeferJobReceipt>false</DeferJobReceipt>
          <DeferInspection>false</DeferInspection>
          <DeferQtyAdjustment>false</DeferQtyAdjustment>
          <DeferInventoryMove>false</DeferInventoryMove>
          <DeferShipments>false</DeferShipments>
          <DeferInventoryCounts>false</DeferInventoryCounts>
          <DeferAssetDisposal>false</DeferAssetDisposal>
          <DeferReturnMaterials>false</DeferReturnMaterials>
          <MXProdServCode></MXProdServCode>
          <MXCustomsDuty></MXCustomsDuty>
          <SendToFSA>false</SendToFSA>
          <ExternalMESSyncRequired>false</ExternalMESSyncRequired>
          <FSAItem>false</FSAItem>
          <FSAEquipment>false</FSAEquipment>
          <BOLClass></BOLClass>
          <FairMarketValue>0</FairMarketValue>
          <SAFTProdCategory></SAFTProdCategory>
          <AttrClassID></AttrClassID>
          <LocationIDNumReq>false</LocationIDNumReq>
          <LocationTrackInv>false</LocationTrackInv>
          <LocationMtlView>false</LocationMtlView>
          <LCNRVReporting>false</LCNRVReporting>
          <LCNRVEstimatedUnitPrice>0</LCNRVEstimatedUnitPrice>
          <MXCustomsUMFrom></MXCustomsUMFrom>
          <LocationFormatID></LocationFormatID>
          <IsServices>false</IsServices>
          <PEDetrGoodServiceCode></PEDetrGoodServiceCode>
          <PEProductServiceCode></PEProductServiceCode>
          <DualUOMClassID></DualUOMClassID>
          <CNProductName></CNProductName>
          <CNWeight>0</CNWeight>
          <CNWeightUOM></CNWeightUOM>
          <CNBonded>false</CNBonded>
          <TrackInventoryAttributes>false</TrackInventoryAttributes>
          <DefaultAttributeSetID>0</DefaultAttributeSetID>
          <AttISOrigCountry>N</AttISOrigCountry>
          <ExternalSchemeID></ExternalSchemeID>
          <ExternalID></ExternalID>
          <CommoditySchemeID></CommoditySchemeID>
          <CommoditySchemeVersion></CommoditySchemeVersion>
          <TrackInventoryByRevision>false</TrackInventoryByRevision>
          <PlanningByRevision>false</PlanningByRevision>
          <CountryNumDescription></CountryNumDescription>
          <EnableExpressCheckOut>false</EnableExpressCheckOut>
          <EnableGlobalLock>false</EnableGlobalLock>
          <EnableGlobalPart>true</EnableGlobalPart>
          <EnableInActive>true</EnableInActive>
          <EnableIUM>false</EnableIUM>
          <EnableRevCharge>false</EnableRevCharge>
          <EnableSerialNum>false</EnableSerialNum>
          <EnableTrackSerialNum>true</EnableTrackSerialNum>
          <EnableUOMClass>false</EnableUOMClass>
          <ExtCoExist>true</ExtCoExist>
          <FSAInstallationCost>0</FSAInstallationCost>
          <FSAInstallationRequired>false</FSAInstallationRequired>
          <FSAInstallationType></FSAInstallationType>
          <FSAInstTypeDesc></FSAInstTypeDesc>
          <GlbFlag>true</GlbFlag>
          <GlbLink></GlbLink>
          <GlbTableAllowUpdTrackDim>false</GlbTableAllowUpdTrackDim>
          <GlbTableAllowUpdTrackLots>false</GlbTableAllowUpdTrackLots>
          <GlbTableAllowUpdTrackSerial>false</GlbTableAllowUpdTrackSerial>
          <HasOnHandQty>false</HasOnHandQty>
          <IsComponent>false</IsComponent>
          <IsCoPart>false</IsCoPart>
          <ISOrigCountryNum>0</ISOrigCountryNum>
          <NextGeneratedLotNum></NextGeneratedLotNum>
          <PEDetrGoodServiceCodeDesc></PEDetrGoodServiceCodeDesc>
          <PEProductServiceCodeDesc></PEProductServiceCodeDesc>
          <PLM>false</PLM>
          <PLMEnabled>false</PLMEnabled>
          <Revision>true</Revision>
          <SalesUMDisp>FT</SalesUMDisp>
          <SNLeadingZeros>false</SNLeadingZeros>
          <SNMaskPrefixLength>0</SNMaskPrefixLength>
          <SNMaskSuffixLength>0</SNMaskSuffixLength>
          <SNNumODigits>0</SNNumODigits>
          <UpdatePartPlant>false</UpdatePartPlant>
          <UpdateSNPartPlant>false</UpdateSNPartPlant>
          <COASegReferences></COASegReferences>
          <HasMRPPlanningAttribute>false</HasMRPPlanningAttribute>
          <UpdatePartPlantOverride>false</UpdatePartPlantOverride>
          <DEPayStatCodeDescr></DEPayStatCodeDescr>
          <DEDenominationDescr></DEDenominationDescr>
          <BitFlag>0</BitFlag>
          <AnalysisCdDescription></AnalysisCdDescription>
          <ClassDescription>WIRE</ClassDescription>
          <CommodityCodeSuppUnitsUOM></CommodityCodeSuppUnitsUOM>
          <CommodityCodeDescription></CommodityCodeDescription>
          <CompanySendToFSA>false</CompanySendToFSA>
          <DualUOMClassIDDescription></DualUOMClassIDDescription>
          <DynAttrValueSetShortDescription></DynAttrValueSetShortDescription>
          <DynAttrValueSetDescription></DynAttrValueSetDescription>
          <FSAssetClassCodeFSAssetClassDesc></FSAssetClassCodeFSAssetClassDesc>
          <Mtl_AnalysisCdDescription></Mtl_AnalysisCdDescription>
          <MXProdServCodeDesc></MXProdServCodeDesc>
          <OnHoldReasonCodeDescription></OnHoldReasonCodeDescription>
          <ProdCodeDescription>OTHER</ProdCodeDescription>
          <RefCategoryDescription></RefCategoryDescription>
          <SerialMaskMaskType>0</SerialMaskMaskType>
          <SerialMaskDescription></SerialMaskDescription>
          <TaxCatIDDescription></TaxCatIDDescription>
          <UOMClassIDDescription>LENGTH</UOMClassIDDescription>
          <WarrantyCodeWarrDescription></WarrantyCodeWarrDescription>
          <XbSystELIEinvoice>true</XbSystELIEinvoice>
          <RowMod></RowMod>
          <Character01></Character01>
          <Character02></Character02>
          <Character03></Character03>
          <Character05></Character05>
          <Number01>0</Number01>
          <Number05>0</Number05>
          <Number06>0</Number06>
          <CheckBox01>true</CheckBox01>
          <CheckBox02>false</CheckBox02>
          <CheckBox03>false</CheckBox03>
          <CheckBox05>false</CheckBox05>
          <CheckBox06>false</CheckBox06>
          <CheckBox07>false</CheckBox07>
          <CheckBox08>false</CheckBox08>
          <ShortChar01></ShortChar01>
          <ShortChar02>Inspect</ShortChar02>
          <ShortChar03></ShortChar03>
          <ShortChar04></ShortChar04>
          <ShortChar05></ShortChar05>
          <ShortChar06></ShortChar06>
          <ShortChar07></ShortChar07>
          <ShortChar08></ShortChar08>
          <ShortChar09></ShortChar09>
          <ShortChar10></ShortChar10>
          <CheckBox04>false</CheckBox04>
          <MinSellQty_c>0.00</MinSellQty_c>
          <Forecasted_c>false</Forecasted_c>
          <ISO13485_c>false</ISO13485_c>
          <TS_16949_c>false</TS_16949_c>
          <CCN_c></CCN_c>
          <ULListed_c>false</ULListed_c>
          <ApprovedMargin_c>0.00</ApprovedMargin_c>
          <TariffCustomer_c>0.00</TariffCustomer_c>
          <TariffSupplier_c>0.00</TariffSupplier_c>
          <Prop65_c>false</Prop65_c>
          <Amortized_c>false</Amortized_c>
          <Commission1_c>0.00</Commission1_c>
          <Commission2_c>0.00</Commission2_c>
          <DiscountPct_c>0.00</DiscountPct_c>
          <CopyExact_c>false</CopyExact_c>
          <CSRMX_c></CSRMX_c>
          <CSRUS_c></CSRUS_c>
          <ASM3CELL_c>false</ASM3CELL_c>
          <Engineer_c></Engineer_c>
          <CopperWeight_c>0.00</CopperWeight_c>
          <UD_SysRevID>AAAAAAQS4V0=</UD_SysRevID>
        </Part>
        <PartPlant>
          <Company>ECM</Company>
          <Plant>MfgSys</Plant>
          <PartNum>10.1761</PartNum>
          <PrimWhse>RAW</PrimWhse>
          <MinimumQty>0.00000000</MinimumQty>
          <MaximumQty>0.00000000</MaximumQty>
          <SafetyQty>0.00000000</SafetyQty>
          <MinOrderQty>1000.00000000</MinOrderQty>
          <LeadTime>10</LeadTime>
          <VendorNum>20</VendorNum>
          <PurPoint>1</PurPoint>
          <BackFlush>false</BackFlush>
          <MfgLotSize>0.00</MfgLotSize>
          <MinMfgLotSize>0.00</MinMfgLotSize>
          <MaxMfgLotSize>0.00</MaxMfgLotSize>
          <MfgLotMultiple>0.00</MfgLotMultiple>
          <DaysOfSupply>30</DaysOfSupply>
          <ReOrderLevel>false</ReOrderLevel>
          <MRPRecalcNeeded>false</MRPRecalcNeeded>
          <ProcessMRP>true</ProcessMRP>
          <GenerateSugg>true</GenerateSugg>
          <GetFromLocalWhse>false</GetFromLocalWhse>
          <ForecastTime>0</ForecastTime>
          <TransferPlant></TransferPlant>
          <SourceType>P</SourceType>
          <TransferLeadTime>0</TransferLeadTime>
          <PrepTime>0</PrepTime>
          <ReceiveTime>0</ReceiveTime>
          <PlanTimeFence>0</PlanTimeFence>
          <ReschedOutDelta>0</ReschedOutDelta>
          <ReschedInDelta>0</ReschedInDelta>
          <NonStock>false</NonStock>
          <PhantomBOM>false</PhantomBOM>
          <BuyerID></BuyerID>
          <PersonID></PersonID>
          <CostMethod>S</CostMethod>
          <AltMethod></AltMethod>
          <KitTime>0</KitTime>
          <KitAllowUpdate>false</KitAllowUpdate>
          <KitShipComplete>true</KitShipComplete>
          <KitAllowChangeParms>false</KitAllowChangeParms>
          <KitBackFlush>false</KitBackFlush>
          <KitPricing>P</KitPricing>
          <KitPrintCompsPS>true</KitPrintCompsPS>
          <KitPrintCompsInv>true</KitPrintCompsInv>
          <ShortHorizonDays>0</ShortHorizonDays>
          <ShortHorizonMinMfgLotSize>0.00</ShortHorizonMinMfgLotSize>
          <ShortHorizonMaxMfgLotSize>0.00</ShortHorizonMaxMfgLotSize>
          <LimitProdYldRecalc>false</LimitProdYldRecalc>
          <QtyBearing>true</QtyBearing>
          <MRPLastRunDate>2024-03-06T00:00:00-05:00</MRPLastRunDate>
          <MRPLastRunTime>36930</MRPLastRunTime>
          <MRPLastScheduledDate>2024-01-02T00:00:00-05:00</MRPLastScheduledDate>
          <ShortHorizonDaysSupp>0</ShortHorizonDaysSupp>
          <SNMask></SNMask>
          <SNMaskExample></SNMaskExample>
          <SNBaseDataType></SNBaseDataType>
          <SNFormat></SNFormat>
          <SNPrefix></SNPrefix>
          <SNMaskSuffix></SNMaskSuffix>
          <SNMaskPrefix></SNMaskPrefix>
          <SNLastUsedSeq></SNLastUsedSeq>
          <UseMaskSeq>false</UseMaskSeq>
          <BuyToOrder>false</BuyToOrder>
          <DropShip>false</DropShip>
          <PcntTolerance>0.00</PcntTolerance>
          <CalcPcnt>false</CalcPcnt>
          <CalcQty>false</CalcQty>
          <CalcValue>false</CalcValue>
          <QtyAdjTolerance>0.00000000</QtyAdjTolerance>
          <QtyTolerance>0</QtyTolerance>
          <ValueTolerance>0</ValueTolerance>
          <DemandQty>0.00000000</DemandQty>
          <ReservedQty>0.00000000</ReservedQty>
          <AllocatedQty>0.00000000</AllocatedQty>
          <XRefPartNum></XRefPartNum>
          <XRefPartType></XRefPartType>
          <NeverReuseMRPJob>false</NeverReuseMRPJob>
          <DeleteMRPJobs>false</DeleteMRPJobs>
          <TotMfgLeadTimeSys>0</TotMfgLeadTimeSys>
          <TotMfgLeadTimeMnl>0</TotMfgLeadTimeMnl>
          <LvlMfgLeadTimeSys>0</LvlMfgLeadTimeSys>
          <LvlMfgLeadTimeMnl>0</LvlMfgLeadTimeMnl>
          <AutoConsumeStock>false</AutoConsumeStock>
          <StartMinLotQty>false</StartMinLotQty>
          <MinLotLeadTime>0</MinLotLeadTime>
          <MfgLeadTimeMnl>false</MfgLeadTimeMnl>
          <MfgLeadTimeEnteredBy></MfgLeadTimeEnteredBy>
          <MinStartQty>0.00000000</MinStartQty>
          <RawMaterial>false</RawMaterial>
          <MultiLevelCTP>false</MultiLevelCTP>
          <RcvInspectionReq>false</RcvInspectionReq>
          <ConsumeSafety>false</ConsumeSafety>
          <SLTVendorNum>0</SLTVendorNum>
          <SLTPurPoint></SLTPurPoint>
          <ShortLeadTime>0</ShortLeadTime>
          <ExternalMES>false</ExternalMES>
          <SysRevID>3440777672</SysRevID>
          <SysRowID>f300f95b-4bca-1d81-e211-07ef50602a98</SysRowID>
          <UrgentLeadTime>0</UrgentLeadTime>
          <UrgentMinOrdQty>0.00000000</UrgentMinOrdQty>
          <UrgentMultQty>0.00</UrgentMultQty>
          <UrgentPurPoint></UrgentPurPoint>
          <UrgentVendorNum>0</UrgentVendorNum>
          <PartRunMRP>false</PartRunMRP>
          <LinkToContract>false</LinkToContract>
          <MMSExclude>false</MMSExclude>
          <MMSSales>false</MMSSales>
          <MMSIssue>false</MMSIssue>
          <MMSHistory>0</MMSHistory>
          <MMSSafetyFactor>0</MMSSafetyFactor>
          <MMSMaxFactor>0.00</MMSMaxFactor>
          <SavedMinimumQty>0.00000000</SavedMinimumQty>
          <SavedMaximumQty>0.00000000</SavedMaximumQty>
          <SavedSafetyQty>0.00000000</SavedSafetyQty>
          <SavedCalculatedUsageQty>0.00000000</SavedCalculatedUsageQty>
          <ACWPercentage>0</ACWPercentage>
          <ACWDays>0</ACWDays>
          <GenNewPCIDDelaySeconds>0</GenNewPCIDDelaySeconds>
          <GenNewPCIDLimitDays>0</GenNewPCIDLimitDays>
          <TopLvlMfgLeadTimeSys>0</TopLvlMfgLeadTimeSys>
          <TopLvlMfgLeadTimeMnl>0</TopLvlMfgLeadTimeMnl>
          <ActualCostingCategoryID></ActualCostingCategoryID>
          <IncludedIntoAllocationBase>false</IncludedIntoAllocationBase>
          <ForecastDaysBefore>0</ForecastDaysBefore>
          <ForecastDaysAfter>0</ForecastDaysAfter>
          <BaseUOMCode>FT</BaseUOMCode>
          <CalculatedLeadTime>10</CalculatedLeadTime>
          <ExtLeadTime>0</ExtLeadTime>
          <SNNumODigits>0</SNNumODigits>
          <UrgentVendorName></UrgentVendorName>
          <UrgentVendorVendorID></UrgentVendorVendorID>
          <DisableQtyBrng>false</DisableQtyBrng>
          <EnableSerialNum>false</EnableSerialNum>
          <ICTrader>false</ICTrader>
          <InActive>false</InActive>
          <OnHandQty>0</OnHandQty>
          <PlantConfCtrlSerialTracking>1</PlantConfCtrlSerialTracking>
          <SNLeadingZeros>false</SNLeadingZeros>
          <HasOnHandQty>false</HasOnHandQty>
          <IsActCostingAllocEnabled>false</IsActCostingAllocEnabled>
          <MaximumQtyNofP>0.00000000</MaximumQtyNofP>
          <MaxMfgLotSizeNofP>0.00000000</MaxMfgLotSizeNofP>
          <MfgLotMultipleNofP>0.00000000</MfgLotMultipleNofP>
          <MinimumQtyNofP>0.00000000</MinimumQtyNofP>
          <MinMfgLotSizeNofP>0.00000000</MinMfgLotSizeNofP>
          <MinOrderQtyNofP>0.00000000</MinOrderQtyNofP>
          <MinStartQtyNofP>0.00000000</MinStartQtyNofP>
          <QtyDisplayOption></QtyDisplayOption>
          <SafetyQtyNofP>0.00000000</SafetyQtyNofP>
          <ShortHorizonMaxMfgLotSizeNofP>0.00000000</ShortHorizonMaxMfgLotSizeNofP>
          <ShortHorizonMinMfgLotSizeNofP>0.00000000</ShortHorizonMinMfgLotSizeNofP>
          <UrgentMinOrdQtyNofP>0.00000000</UrgentMinOrdQtyNofP>
          <UrgentMultQtyNofP>0.00000000</UrgentMultQtyNofP>
          <BitFlag>8</BitFlag>
          <BuyerIDName></BuyerIDName>
          <PartTrackInventoryAttributes>false</PartTrackInventoryAttributes>
          <PartAttrClassID></PartAttrClassID>
          <PartSellingFactor>1.00000000</PartSellingFactor>
          <PartTrackLots>false</PartTrackLots>
          <PartTrackSerialNum>false</PartTrackSerialNum>
          <PartTrackDimension>false</PartTrackDimension>
          <PartIUM>FT</PartIUM>
          <PartPricePerCode>E</PartPricePerCode>
          <PartPartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartPartDescription>
          <PartSalesUM>FT</PartSalesUM>
          <PersonName></PersonName>
          <PlantName>ELECTRI-CORD MFG - PA PLANT</PlantName>
          <PrimWhseDescription>RAW MATERIAL</PrimWhseDescription>
          <SerialMaskMaskType>0</SerialMaskMaskType>
          <SerialMaskDescription></SerialMaskDescription>
          <TransferPlantName></TransferPlantName>
          <VendorNumAddress1>PO BOX 26157</VendorNumAddress1>
          <VendorNumState>PA</VendorNumState>
          <VendorNumCountry>UNITED STATES</VendorNumCountry>
          <VendorNumCity>COLLEGEVILLE</VendorNumCity>
          <VendorNumCurrencyCode>BASE</VendorNumCurrencyCode>
          <VendorNumDefaultFOB>FOBSHIP</VendorNumDefaultFOB>
          <VendorNumAddress2></VendorNumAddress2>
          <VendorNumZIP>26157</VendorNumZIP>
          <VendorNumTermsCode>N60</VendorNumTermsCode>
          <VendorNumAddress3></VendorNumAddress3>
          <VendorNumName>ALLIED WIRE &amp; CABLE</VendorNumName>
          <VendorNumVendorID>1018</VendorNumVendorID>
          <RowMod></RowMod>
          <Character01></Character01>
          <Character02></Character02>
          <Character03></Character03>
          <Character04></Character04>
          <Character05></Character05>
          <Character06></Character06>
          <Number01>0.000000000</Number01>
          <CheckBox01>false</CheckBox01>
          <ToolingCap_c>0.00</ToolingCap_c>
          <UD_SysRevID>AAAAAAQMCfI=</UD_SysRevID>
        </PartPlant>
        <PartRev>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <RevisionNum>-</RevisionNum>
          <RevShortDesc>Default</RevShortDesc>
          <RevDescription></RevDescription>
          <Approved>true</Approved>
          <ApprovedDate>2024-04-17T00:00:00-04:00</ApprovedDate>
          <ApprovedBy>ComTec</ApprovedBy>
          <EffectiveDate>2024-04-17T00:00:00-04:00</EffectiveDate>
          <TLRLaborCost>0</TLRLaborCost>
          <TLRBurdenCost>0</TLRBurdenCost>
          <TLRMaterialCost>0</TLRMaterialCost>
          <TLRSubcontractCost>0</TLRSubcontractCost>
          <TLRMtlBurCost>0</TLRMtlBurCost>
          <TLRSetupLaborCost>0</TLRSetupLaborCost>
          <TLRSetupBurdenCost>0</TLRSetupBurdenCost>
          <LLRLaborCost>0</LLRLaborCost>
          <LLRBurdenCost>0</LLRBurdenCost>
          <LLRMaterialCost>0</LLRMaterialCost>
          <LLRSubcontractCost>0</LLRSubcontractCost>
          <LLRMtlBurCost>0</LLRMtlBurCost>
          <LLRSetupLaborCost>0</LLRSetupLaborCost>
          <LLRSetupBurdenCost>0</LLRSetupBurdenCost>
          <DrawNum></DrawNum>
          <ECO></ECO>
          <Method>false</Method>
          <AutoRecOpr>0</AutoRecOpr>
          <FinalOpr>0</FinalOpr>
          <PDMObjID></PDMObjID>
          <Configured>false</Configured>
          <WebConfigured>false</WebConfigured>
          <ShowInputPrice>false</ShowInputPrice>
          <AltMethod></AltMethod>
          <AltMethodDesc></AltMethodDesc>
          <Plant>MN</Plant>
          <ParentAltMethod></ParentAltMethod>
          <UseStaging>false</UseStaging>
          <UseAltRevForParts>false</UseAltRevForParts>
          <OwnershipStatus></OwnershipStatus>
          <ExtConfig>false</ExtConfig>
          <ValRefDes>false</ValRefDes>
          <PcGlobalPart>false</PcGlobalPart>
          <PcEntprsConf>false</PcEntprsConf>
          <GlobalRev>false</GlobalRev>
          <RoughCutCode></RoughCutCode>
          <RMAInspPlan></RMAInspPlan>
          <RMASpecID></RMASpecID>
          <RMASampleSize>0</RMASampleSize>
          <RMASampleSizePct>0</RMASampleSizePct>
          <BasePartNum></BasePartNum>
          <BaseRevisionNum></BaseRevisionNum>
          <ConfigID></ConfigID>
          <RegenConfig>false</RegenConfig>
          <SIValuesGroupSeq>0</SIValuesGroupSeq>
          <SIValuesHeadNum>0</SIValuesHeadNum>
          <ExternalMES>false</ExternalMES>
          <SysRevID>3441156499</SysRevID>
          <SysRowID>cf469999-a5fa-4667-a855-083e04d9fbc3</SysRowID>
          <ProcessMode>S</ProcessMode>
          <DefaultConfigPart>false</DefaultConfigPart>
          <CoPartsReqQty>0</CoPartsReqQty>
          <MtlCostPct>0</MtlCostPct>
          <LaborCostPct>0</LaborCostPct>
          <CoPartsPerOp>0</CoPartsPerOp>
          <CreatedBy>ComTec</CreatedBy>
          <CreatedOn>2024-04-17T16:55:30.773-04:00</CreatedOn>
          <ChangedBy>ComTec</ChangedBy>
          <ChangedOn>2024-04-17T17:04:07.2197473-04:00</ChangedOn>
          <ExternalMESSyncRequired>false</ExternalMESSyncRequired>
          <CNCustomsBOM>false</CNCustomsBOM>
          <ProcessMfgID></ProcessMfgID>
          <ProcessMfgType></ProcessMfgType>
          <ProcessMfgDescription></ProcessMfgDescription>
          <UseAdvancedStaging>false</UseAdvancedStaging>
          <ProcessMfgLastGroupID></ProcessMfgLastGroupID>
          <DisableApproved>false</DisableApproved>
          <ECOGroup></ECOGroup>
          <HasCoParts>false</HasCoParts>
          <ParentAltMethodDesc></ParentAltMethodDesc>
          <ParentPartNum></ParentPartNum>
          <ParentRevisionNum></ParentRevisionNum>
          <ProdCode></ProdCode>
          <RevStatusAsOfDate>0</RevStatusAsOfDate>
          <SpecHedDescription></SpecHedDescription>
          <vQty>0.00000000</vQty>
          <Class></Class>
          <NonStock>false</NonStock>
          <IsRootNode>false</IsRootNode>
          <EngineeringApproved>false</EngineeringApproved>
          <BitFlag>8</BitFlag>
          <InspPlanDescription></InspPlanDescription>
          <PartDescriptionTrackDimension>false</PartDescriptionTrackDimension>
          <PartDescriptionSellingFactor>1.00000000</PartDescriptionSellingFactor>
          <PartDescriptionPartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartDescriptionPartDescription>
          <PartDescriptionIUM>FT</PartDescriptionIUM>
          <PartDescriptionTrackLots>false</PartDescriptionTrackLots>
          <PartDescriptionPricePerCode>E</PartDescriptionPricePerCode>
          <PartDescriptionSalesUM>FT</PartDescriptionSalesUM>
          <PartDescriptionTrackSerialNum>false</PartDescriptionTrackSerialNum>
          <PartDescriptionTypeCode>P</PartDescriptionTypeCode>
          <PcStatusConfigType></PcStatusConfigType>
          <PlantName>ELECTRI-CORD MFG - MN PLANT</PlantName>
          <RoughCutParamDescription></RoughCutParamDescription>
          <RowMod></RowMod>
          <CheckBox01>true</CheckBox01>
          <CheckBox02>false</CheckBox02>
          <CheckBox03>false</CheckBox03>
          <ShortChar06></ShortChar06>
          <PPAP_c>false</PPAP_c>
          <GoldenSample_c>false</GoldenSample_c>
          <JobPrefix_c>FRP</JobPrefix_c>
          <UD_SysRevID>AAAAAM0b4Xs=</UD_SysRevID>
        </PartRev>
        <PartAudit>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <RevisionNum>-</RevisionNum>
          <ChangeDate>2024-04-17T00:00:00-04:00</ChangeDate>
          <ChangeTime>47047</ChangeTime>
          <ChangedBy>ComTec</ChangedBy>
          <ChangeDescription>test</ChangeDescription>
          <AltMethod></AltMethod>
          <SysRevID>3441156500</SysRevID>
          <SysRowID>ed1d8ae0-8ae9-441e-95bc-5dc567892ed1</SysRowID>
          <ProcessMfgID></ProcessMfgID>
          <DspChangeTime> 1:04 PM</DspChangeTime>
          <BitFlag>0</BitFlag>
          <PartNumTrackDimension>false</PartNumTrackDimension>
          <PartNumTrackLots>false</PartNumTrackLots>
          <PartNumPartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartNumPartDescription>
          <PartNumPricePerCode>E</PartNumPricePerCode>
          <PartNumTrackSerialNum>false</PartNumTrackSerialNum>
          <PartNumIUM>FT</PartNumIUM>
          <PartNumSalesUM>FT</PartNumSalesUM>
          <PartNumSellingFactor>1.00000000</PartNumSellingFactor>
          <RevisionNumRevShortDesc></RevisionNumRevShortDesc>
          <RevisionNumRevDescription></RevisionNumRevDescription>
          <RowMod></RowMod>
        </PartAudit>
        <PartCOPart>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <RevisionNum>-</RevisionNum>
          <CoPartNum>10.1761</CoPartNum>
          <CoRevisionNum>-</CoRevisionNum>
          <PartsPerOp>1</PartsPerOp>
          <LbrCostBase>1</LbrCostBase>
          <MtlCostBase>1</MtlCostBase>
          <PartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartDescription>
          <IUM>FT</IUM>
          <AltMethod></AltMethod>
          <PreventSugg>false</PreventSugg>
          <SysRevID>3441156477</SysRevID>
          <SysRowID>13687c28-5ea7-4252-9a53-97ece7b675b2</SysRowID>
          <PrimaryCost>false</PrimaryCost>
          <ProcessMfgID></ProcessMfgID>
          <EnablePreventSugg>false</EnablePreventSugg>
          <PartMasterPart>false</PartMasterPart>
          <ProcessMode></ProcessMode>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartCOPart>
        <PartWhse>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <WarehouseCode>RAW</WarehouseCode>
          <DemandQty>0.00000000</DemandQty>
          <ReservedQty>0.00000000</ReservedQty>
          <AllocatedQty>0.00000000</AllocatedQty>
          <PickingQty>0.00000000</PickingQty>
          <PickedQty>0.00000000</PickedQty>
          <OnHandQty>0.00000000</OnHandQty>
          <NonNettableQty>0.00000000</NonNettableQty>
          <BuyToOrderQty>0.00000000</BuyToOrderQty>
          <SalesDemandQty>0.00000000</SalesDemandQty>
          <SalesReservedQty>0.00000000</SalesReservedQty>
          <SalesAllocatedQty>0.00000000</SalesAllocatedQty>
          <SalesPickingQty>0.00000000</SalesPickingQty>
          <SalesPickedQty>0.00000000</SalesPickedQty>
          <JobDemandQty>0.00000000</JobDemandQty>
          <JobReservedQty>0.00000000</JobReservedQty>
          <JobAllocatedQty>0.00000000</JobAllocatedQty>
          <JobPickingQty>0.00000000</JobPickingQty>
          <JobPickedQty>0.00000000</JobPickedQty>
          <UnfirmJobDemandQty>0.00000000</UnfirmJobDemandQty>
          <TFOrdDemandQty>0.00000000</TFOrdDemandQty>
          <TFOrdReservedQty>0.00000000</TFOrdReservedQty>
          <TFOrdAllocatedQty>0.00000000</TFOrdAllocatedQty>
          <TFOrdPickingQty>0.00000000</TFOrdPickingQty>
          <TFOrdPickedQty>0.00000000</TFOrdPickedQty>
          <KBCode></KBCode>
          <MinimumQty>0.00000000</MinimumQty>
          <MaximumQty>0.00000000</MaximumQty>
          <SafetyQty>0.00000000</SafetyQty>
          <KBPONUM>0</KBPONUM>
          <KBPOLine>0</KBPOLine>
          <KBWarehouseCode></KBWarehouseCode>
          <KBBinNum></KBBinNum>
          <KBPlant></KBPlant>
          <KBQty>0.00000000</KBQty>
          <PcntTolerance>0.00</PcntTolerance>
          <CalcPcnt>false</CalcPcnt>
          <CalcQty>false</CalcQty>
          <CalcValue>false</CalcValue>
          <QtyAdjTolerance>0.00000000</QtyAdjTolerance>
          <CalcQtyAdj>false</CalcQtyAdj>
          <MinAbc></MinAbc>
          <SystemAbc>C</SystemAbc>
          <ManualABC>false</ManualABC>
          <LastCCDate>2021-05-22T00:00:00-04:00</LastCCDate>
          <OvrrideCountFreq>false</OvrrideCountFreq>
          <CountFreq>0</CountFreq>
          <QtyTolerance>0</QtyTolerance>
          <ValueTolerance>0</ValueTolerance>
          <SysRevID>2173027525</SysRevID>
          <SysRowID>f300f95b-4bca-1d81-e211-07ef0cc42998</SysRowID>
          <Plant>MfgSys</Plant>
          <DefaultWhse>true</DefaultWhse>
          <PrimBinNum></PrimBinNum>
          <TotalDemand>0.00000000</TotalDemand>
          <PrimBinNumDescription></PrimBinNumDescription>
          <KBActionCode></KBActionCode>
          <KBActionDesc></KBActionDesc>
          <PlantOwner>MfgSys</PlantOwner>
          <MaxQtyUOM>FT</MaxQtyUOM>
          <MinQtyUOM>FT</MinQtyUOM>
          <SafetyQtyUOM>FT</SafetyQtyUOM>
          <IUM></IUM>
          <BitFlag>0</BitFlag>
          <KBBinNumDescription></KBBinNumDescription>
          <KBCodeKBActionCode></KBCodeKBActionCode>
          <KBCodeKBDescription></KBCodeKBDescription>
          <KBPlantName></KBPlantName>
          <KBWarehouseCodeDescription></KBWarehouseCodeDescription>
          <PartNumIUM>FT</PartNumIUM>
          <PartNumPricePerCode>E</PartNumPricePerCode>
          <PartNumTrackSerialNum>false</PartNumTrackSerialNum>
          <PartNumSalesUM>FT</PartNumSalesUM>
          <PartNumSellingFactor>1.00000000</PartNumSellingFactor>
          <PartNumTrackLots>false</PartNumTrackLots>
          <PartNumPartDescription>1/0 AWG WELDING CABLE ANIXTER 5J-1011</PartNumPartDescription>
          <PartNumTrackDimension>false</PartNumTrackDimension>
          <WarehouseDescription>RAW MATERIAL</WarehouseDescription>
          <RowMod></RowMod>
        </PartWhse>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>FT</UOMCode>
          <ConvFactor>12.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>true</TrackOnHand>
          <NetVolume>0.00000</NetVolume>
          <NetVolumeUOM>FZ</NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>16262168</SysRevID>
          <SysRowID>f300f95b-4bca-1d81-e211-07efb64a2b98</SysRowID>
          <ConvFromUOM>1 FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 12.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>FOOT</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>25PER</UOMCode>
          <ConvFactor>300.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>9f879584-70ec-424d-9a95-00b7a0a4074f</SysRowID>
          <ConvFromUOM>1 25PER</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 300.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>25 FEET PER BOX</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>IN</UOMCode>
          <ConvFactor>1.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>bbe1a5fc-a3a6-dc9a-df11-0310bbf4188c</SysRowID>
          <ConvFromUOM>1 IN</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 1.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>INCHES</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>M</UOMCode>
          <ConvFactor>39.3701000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>803c49c6-b6c7-6aa1-e211-e200e66d498c</SysRowID>
          <ConvFromUOM>1 M</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 39.3701000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>METER</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>R100FT</UOMCode>
          <ConvFactor>1200.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>f56de3bb-7bb7-829e-e211-cc01774f108a</SysRowID>
          <ConvFromUOM>1 R100FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 1200.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>100 FOOT ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL18YD</UOMCode>
          <ConvFactor>648.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>ee996ea1-27a7-b796-e111-9ffe8360e5fa</SysRowID>
          <ConvFromUOM>1 RL18YD</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 648.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>18 YARD ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL33FT</UOMCode>
          <ConvFactor>396.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>832b8a79-bdbd-ecac-e211-cc011891cfb3</SysRowID>
          <ConvFromUOM>1 RL33FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 396.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>33 FOOT ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL36YD</UOMCode>
          <ConvFactor>1296.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>8de39d3f-c864-0f83-e211-840d5cedaf9c</SysRowID>
          <ConvFromUOM>1 RL36YD</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 1296.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>36 YARD ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL50FT</UOMCode>
          <ConvFactor>600.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>7d591cde-c592-429b-8402-4f9057a3a443</SysRowID>
          <ConvFromUOM>1 RL50FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 600.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>50 FOOT ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL60FT</UOMCode>
          <ConvFactor>720.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>e462213a-5203-49fa-8094-0a7c50bd6cb9</SysRowID>
          <ConvFromUOM>1 RL60FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 720.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>60 FOOT ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL60YD</UOMCode>
          <ConvFactor>2160.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>e70b631d-1631-4c8a-e011-cfc19b79c1ea</SysRowID>
          <ConvFromUOM>1 RL60YD</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 2160.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>60 YARD ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>RL66FT</UOMCode>
          <ConvFactor>792.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>82a8546c-7912-fc88-e311-d58210f0d02d</SysRowID>
          <ConvFromUOM>1 RL66FT</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 792.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>66 FOOT ROLL</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>ST48IN</UOMCode>
          <ConvFactor>48.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>c137853b-77ea-f781-e111-7301695d5180</SysRowID>
          <ConvFromUOM>1 ST48IN</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 48.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>48 INCH STICK</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>TQ</UOMCode>
          <ConvFactor>12000.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>bbe1a5fc-a3a6-dc9a-df11-0310a252b6cf</SysRowID>
          <ConvFromUOM>1 TQ</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 12000.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>THOUSAND FEET</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
        <PartUOM>
          <Company>ECM</Company>
          <PartNum>10.1761</PartNum>
          <UOMCode>YD</UOMCode>
          <ConvFactor>36.0000000</ConvFactor>
          <Active>true</Active>
          <TrackOnHand>false</TrackOnHand>
          <NetVolume>0</NetVolume>
          <NetVolumeUOM></NetVolumeUOM>
          <HasBeenUsed>false</HasBeenUsed>
          <ConvOperator>*</ConvOperator>
          <WebUOM>false</WebUOM>
          <SysRevID>0</SysRevID>
          <SysRowID>bbe1a5fc-a3a6-dc9a-df11-03102b34dbb0</SysRowID>
          <ConvFromUOM>1 YD</ConvFromUOM>
          <ConvOverrride>false</ConvOverrride>
          <ConvToUOM>= 36.0000000 IN</ConvToUOM>
          <EAN13></EAN13>
          <EAN14></EAN14>
          <EAN8></EAN8>
          <EnableConvFactor>false</EnableConvFactor>
          <EnableTrackOnHand>false</EnableTrackOnHand>
          <GTIN14></GTIN14>
          <HIBC></HIBC>
          <PartSpecific>false</PartSpecific>
          <UOMDesc>YARD</UOMDesc>
          <UPC12></UPC12>
          <BaseUOMCode>IN</BaseUOMCode>
          <DispPkgCode></DispPkgCode>
          <DispPkgCodeDesc></DispPkgCodeDesc>
          <DispPkgDisplaySeq>0</DispPkgDisplaySeq>
          <DispPkgIsDefault>false</DispPkgIsDefault>
          <PartSpecificPkgCode>false</PartSpecificPkgCode>
          <DispPkgDisplayHidden>false</DispPkgDisplayHidden>
          <StandardUpdate>false</StandardUpdate>
          <BitFlag>0</BitFlag>
          <RowMod></RowMod>
        </PartUOM>
      </PartDataSet>
    </parameter>
    <parameter name="CallContext" type="Ice.Bpm.Context.ContextDataSet">
      <ContextDataSet xmlns="http://www.epicor.com/Ice/300/Bpm/Context">
        <BpmData>
          <SysRowID>00000000-0000-0000-0000-000000000000</SysRowID>
        </BpmData>
      </ContextDataSet>
    </parameter>
  </parameters>
</tracePacket>

Max_Delgado · April 17, 2024, 5:55pm

For some reason, I do not think this is displaying correctly on here…

Mark_Wonsil · April 17, 2024, 6:05pm

When a Revision is approved, a PartAudit record is created and it needs to be filled out, including the change made. If you look at the trace of the approval when running manually, you will see this record populated.

Topic		Replies	Views
Epicor Functions and BAQs Epicor ERP 10 functions	54	18149	March 9, 2023
Epicor functions and BAQs Epicor ERP 10 baq , functions	25	12329	August 2, 2024
Creating my first function Kinetic ERP	15	1527	July 1, 2024
BAQ Question for keeping results separate Epicor ERP 10 baq	44	2724	January 27, 2023
Epicor Functions and BAQs - the sequel Kinetic ERP baq , bpm-methods , functions	1	1825	June 21, 2022

BAQ in Function

Related Topics
